Intended Use
The Bosch BT-EXACT/BT-ANGLE EXACT and EXAConnecT
screwdriving system is intended for driving and loosening
screws and tightening and loosening nuts in the specified di-
mension and performance range. It is not intended for docu-
menting the torque or rotation angle of a screw connection.
The OK or NOK signal results exclusively from a shut-off signal
of the mechanical shut-off clutch, which has to be corre-
spondingly calibrated and which requires continual re-check-
ing. This OK or NOK signal does not permit any conclusions to
be drawn about the quality of a screw connection.
These signals can be analysed and documented using the
EXAConnecT access point and its software. Any modification
of the hardware and/or software or the connection of addi-
tional hardware fundamentally excludes any liability of Robert
Bosch GmbH.
Country-specific instructions
European Union
This screwdriving system may be used in all countries of the
European Union. In France, the use of Bluetooth is only toler-
ated. Please inform yourself of the regulations of the region of
use.
North America
The access point has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules (Federal Communications Commission). These
limits are designed to provide reasonable protection against
harmful interference when the access point is operated in a
commercial environment. This access point generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer's instruction
manual, may cause interference to radio communications.
Operation of this access point in a residential area is likely to
cause harmful interference, in which case the user will be re-
quired to correct the interference at his own expense.
Product Features
The numbering of the product features refers to the illustra-
tions on the graphics pages.
1 EXAConnecT access point
2 Phillips screws
3 Green LED indicator (ready for operation)
4 Yellow LED indicator (Ethernet connection)
5 Blue LED indicator (Bluetooth connection)
6 Display: Display for status codes
7 Service cover plate
8 Maintenance cover plate
9 Holes for wall fastening
10 Seal ring
Bosch Power Tools
11 Cable gland (PG 16)
12 Locknut for cable gland
13 Ground terminal
14 RS232 interface
15 Backup battery
16 DIP switch for access point
17 Reset button for access point
18 Terminal strip
19 Power supply connection
20 Button cell for real time clock
21 Button cell socket
22 M4 Phillips screws
23 Mains cable (3-wire)*
24 Plastic bar for insulating the power supply connection
from the other connections
25 Network cable (Ethernet)*
26 Mains cable (5-wire)*
27 I/O module expansion module
28 Phillips screws
29 DIP switch for I/O module
30 Reset button for I/O module
31 Red LED indicator (error)
32 Green LED indicator (ready for operation)
33 RJ45 interface (Ethernet)
34 Cable gland (PG 16)
35 Service cover plate
36 Seal ring
Optional system expansions
37 Mechanical button/switch
38 Signal lamp
39 Release button*
40 Cable of the release button
41 Interface converter
42 Barcode scanner (RS232 or USB)
43 Yellow signal lamp
44 Blue signal lamp
45 Green signal lamp
46 Red signal lamp
47 External power supply of the signal lamp
Configuration software
48 Symbol field for screwdriver
49 Screwdriver serial number tab
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
