12.7

Calibration of scales

12.7.1

Calibrating internal refrigerant cylinder

i
The internal refrigerant cylinder is calibrated at the
factory.
i
Contact customer service for calibration of the inter-
nal refrigerant cylinder.
12.7.2

Fresh oil and used oil scales

i
This section describes the procedure for the fresh
oil scale. Perform the same steps to calibrate the
used oil scale.
Calibration
!
Do not exert excessive force when removing or in-
serting the UV dye, fresh oil and used oil bottles, as
this could damage the scales.
!
Observe the ACS 511 menu prompting.
1. Call up start screen.
2. Press <3> and <Flush> simultaneously and release.
 The message ENTER CODE 0000
1111
and confirm with E.
3. Enter code
4. Select "IN OIL CALIBRATION" with o u and confirm
with E.
 Calibration – fresh oil – zero position (en-
ter weight).
5. Remove the fresh oil bottle from the scales.
0000 ml
and confirm with E.
6. Enter
 Calibration weight is displayed.
7. Fill fresh oil bottle with exactly 250 ml of fresh oil
(fresh oil scale).
8. Attach fresh oil bottle to fresh oil scales.
340 ml
(320 ml) and confirm with E.
9. Enter
i
For calibrating the fresh-oil weigher, a value of
340 ml (250 ml of oil in the bottle + 90 ml of tare
weight for the bottle) must be entered.
i
For calibrating the used-oil weigher, a value of
320 ml (250 ml of oil in the bottle + 70 ml of tare
weight for the bottle) must be entered.
"
Fresh oil scales are calibrated.
Robert Bosch GmbH
12.8
12.8.1
i
The firmware (software) can be updated by way of a
PS2 stick. Further information can be obtained from
customer service.
12.8.2
i
The vehicle database can be updated annually by
way of a PS2 stick. Further information can be ob-
tained from customer service.
!
Do not switch off ACS 511 during update process.
!
Observe the ACS 511 menu prompting.
1. Call up start screen.
2. Press <3> and <Flush> simultaneously and release.
 The message
3. Enter code
4. Select "DATABASE UPDATE" with o u and confirm
with E.
 INSERT THE KEY
5. Remove plastic cover (input PS2 stick) between
menu key and stop key.
is displayed. 6. Insert PS2 stick.
7. Activate or deactivate with o u and confirm with E.
 The update is performed.
"
Data base is updated.
i
Return with <Stop>.
Maintenance | ACS 511 | 59

Software update

Firmware

Vehicle database

ENTER CODE 0000
2222
and confirm with E.
is displayed.
S P00 D00 001
en
is displayed.
|
