Whirlpool SMP 778 C/NE/IXL Bedienungsanleitung Seite 3

Owner's manual
Please note: Do not cover the display or the slide touchscreen with accessories.
If a utensil is covering one of the displays, the hob may not function properly. On
the right display, the message "CHECK TOUCH AREA, remove the object within one
minute" will appear. Remove the object and wait until the message disappears. If
the problem persists, disconnect and reconnect the power to the cooktop.
In the cooking zones close to the control panel, it is advisable to keep pots and
pans inside the markings (taking both the bottom of the pan and the upper edge
into consideration, as this tends to be larger).
This prevents excessive overheating of the touchpad. When grilling or frying,
please use the rear cooking zones wherever possible.
3.
Select the cooking zone or exible area from the left-hand display.
4.
Set the desired power level by pressing or moving your nger horizontally
across the slide touchscreen.
The power level set will appear in the pane of the cooking zone selected.
Each cooking zone o ers a range of di erent heat settings, from "1" (minimum
power) to "18" (maximum power).
Using the slide touchscreen, you can also select the quick heat function, which
will appear on the display with the letter "P".
Please note: If the pot is not suitable for induction cooking, is not positioned correctly
or is not of an appropriate size, the cooking zone pane will ash. If no pot is detected
within 30 seconds of making the selection, the cooking zone switches o .
To deactivate the cooking zones:
Select the cooking zone in the left-hand display and press the "OFF" button at
the top of the slide touchscreen. If the cooking zone is still hot, the residual heat
indicator "H" will appear in the corresponding pane.
ADD POT
When using a cooking area composed of several zones, the pot can be placed
anywhere on the active area. The hob will automatically recognise the actual
positioning of the pot.
If you wish to add an additional pot to the active cooking area, use the "Add
pot" command to allow the hob to detect the new pot.
KEY LOCK
To prevent accidental activation of the hob during cleaning, or to prevent
the controls from being changed accidentally whilst cooking, press the "Key
lock" button for 3 seconds: a beep and a warning light indicate that this
function has been activated.
The control panel will be locked, with the exception of the o button.
To reactivate the controls, press the "Key Lock"
The warning light switches o and the hob is active again.
When the hob is o , you can use the right-hand display as a timer.
To activate the timer:
1.
2.
3.
4.
To change or deactivate the timer:
1.
2.
The cooking zones can be programmed to switch o automatically.
To set the cooking time:
1.
2.
3.
4.
To change or deactivate the cooking timer:
1.
2.
3.
A cooking time can be set for each zone or exible area by following the same
steps.
button again for 3 seconds.
TIMER
Switch on the hob.
Press the hourglass icon that appears on the manage functions display.
Use the "+"/"–" buttons to set the time.
When the set time has elapsed, an acoustic signal sounds.
Press the hourglass icon that appears on the manage functions display.
Use the "+" and "–" buttons to reset the desired time, or press the "STOP"
button to turn o the timer.
SETTING THE COOKING TIME
Select the cooking zone and set the required power level.
Press the stopwatch icon that appears on the manage functions display.
Use the "+"/"–" buttons to set the time.
Once the set time has elapsed, an acoustic signal sounds and the cooking
zone switches o automatically.
Select the active cooking zone.
Press the stopwatch icon that appears on the manage functions display.
Use the "+" and "–" buttons to reset the desired time, or press the "STOP"
button to cancel the set cooking time.
EN
