Operation - Kärcher WPD 100 Advanced Originalbetriebsanleitung

Menu initial start-up
 Set the appliance switch to "I".
Display
Begin initiation? YES (start initial start-up) Enter
1 Button Plus / increase
2 Button Minus / decrease
3 Enter key
4 Button Back/Stop
5 LED
6 Text messages
With the "plus" and "minus" buttons sub-menus can be
selected and adjustable values (flashing display) can be
increased or reduced.
With the "Enter" button indications on the display or en-
tries can be confirmed.
With the "Back" button, you can return to the previous
step or leave the menu level.
Display
Language (language selection)
>Available languages<
>Selected language<
Actual date / time
>Set day (display is flashing)<
>Set month (display is flashing)<
>Set year (display is flashing)<
>Set hours (display is flashing)<
>Set minutes (display is flashing)<
>Date/time set<
Filter inserted?
Water supply connected?
Canister under the outlet?
First use is running mm:ss
Note:
Upon the initial start-up, the lines of the individual types
of water are rinsed. The process takes approximately
18 minutes.
The water that is dispensed during the rinsing process
is not fit for human consumption!
The receptacle underneath the water outlet must be
emptied several times during the rinsing process.
Display
First use is running mm:ss
First use interrupted continue!
 Empty the container and place it under the water
outlet.
Display
First use interrupted continue!
After completion of the initial start-up, a hygienisation
must be performed.
Display
Run the disinfection now. Otherwise ap-
pliance hygiene is not safeguarded.
Yes
Later
After completion of the disinfection/hygienisation, the
device is ready for operation.
Operator and display elements
Button
1 Button for unchilled water
2 Button for chilled water
3 Button for carbonated water *
Button
4 Button for hot water *
Enter 5 LEDs blue and red
6 Drip pan
Plus / Minus
7 Water dispenser
Enter
8 Display "I" (information)
9 Display "e" (Eco mode)
Enter
* Depending on the unit equipment
Enter
Enter
Note:
The buttons are sensor buttons. They can be operated
Enter
with merely a light touch.
Enter
– If an "I" is shown on the bottom left of the display
Enter
this points to an information that is deposited in the
user menu under "Error messages" Reading of the
Enter
error messages is described in Chapter "User
menu".
Enter
– If an "e" is shown at the top left of the display, the
Enter
Eco mode is activated. In the process, the hot wa-
ter provision (option) is deactivated and the cooling
performance reduced.
This reduces the energy consumption.
Heating or chilling may take longer afterwards. Ac-
tivating or deactivating the Eco mode is described
in the Chapter "User menu".
Button
Back (X)
Button
Enter
Button
Enter
Back
1 MENU button
2 SD card slot
3 Button RESET
4 Service interface

Operation

4
-
EN
Support leg (option)
1 Cup dispenser
(see "Accessories" for suitable cups)
2 Door base
3 Door lock
Requesting water dispensing
1 Display unchilled water
2 Display chilled water
3 Display carbonated water *
4 Display hot water *
* Depending on the unit equipment
 Place the receptacle in the middle of the drip pan.
 Press the button for the selected water type and
hold it down until the desired amount of water has
been dispensed into the receptacle.
Indication with "Portion customizing Standard"
1 Portioning 1.0 litre
2 Portioning 0.5 litre
3 Portioning 0.2 litre
4 Symbol button "STOP"
If the option "Portion customizing Standard" is activated
in the user settings, you can choose between 3 prede-
fined portionings (1.0, 0.5 and 0.2 l) after selection of
the water type (settings see Chapter "Care and mainte-
nance / user menu / operating parameters").
Indication with "Portion customizing Adapted"
Note:
The display symbols and portioning are variable and
can be set by the operator (see Chapter "User menu/
user settings").
1 Portioning large
2 Portioning medium
3 Portioning small
4 Symbol button "STOP"
21
