DK12-11-IO
Anhang
9.2.2

DK12 spezifische Parameter

Die folgenden Parameter dienen zur Parametrierung, Konfiguartion und Diagnose der DK12-
11-IO spezifischen Funktionen.
Index
hex dezimal Name
0x50 80 Schwellwert (on)
0x51 81 Schwellwert (off)
0x54 84 Kontrastschalter
Polarität
0x55 85 Senderfarbe
0x68 104 Teach Mode
0x69 105 Teach Result
sub1 Teach Status
sub2 Teach Quality Factor
0x6A 106 Teach Value M (RGB)
sub1 Red Intensity M
sub2 Green Intensity M
sub3 Blue Intensity M
0x6B 107 Teach Value B (RGB)
sub1 Red Intensity B
sub2 Green Intensity B
sub3 Blue Intensity B
0x70 112 Output Mode Control
(L/D on)
36
Typ Datentyp
R unsigned
Integer 8
R unsigned
Integer 8
R unsigned
Integer 8
R unsigned
Integer 8
R/W unsigned
Integer 8
R Record
R unsigned
Integer 8
R unsigned
Integer 8
R/W Record
R/W unsigned
Integer 8
R/W unsigned
Integer 8
R/W unsigned
Integer 8
R/W Record
R/W unsigned
Integer 8
R/W unsigned
Integer 8
R/W unsigned
Integer 8
R/W unsigned
Integer 8
Wert
0x00 - 0xff
0x00 - 0xff
0x00 - An über Schwellwert
0x01 - An unter Schwellwert
0x00 - aus
0x01 - rot
0x02 - grün
0x03 - blau
0x04 - alle (weis)
0x00 - operate
0x01 - teach M
0x02 - teach B
0x03 - teach dynamic
0x0F - evaluate
0x1F - enable local teach-in
2 entries
0bX0XX 0000 - no new value
0bX0XX 0001 - new value M
0bX0XX 0010 - new value B
0bX0XX 0011 - new value M+B
0bX0X1 XXXX- local teach-in
active
0b0010 0000 - sensor test
operation
0b10XX XXXX- teach fail
0x00 - 0x64 (see definition)
3 entries
0x00 - 0xFF
0x00 - 0xFF
0x00 - 0xFF
3 entries
0x00 - 0xFF
0x00 - 0xFF
0x00 - 0xFF
== 0x00 - normal (default)
<> 0x00 - inverted
