The area must be reachable without any rises
or drops greater than those allowed. Whether
a zone is to be defi ned a "secondary area"
also depends on the size of the primary area.
The larger the primary area, the harder it will
be to reach narrow passages. More generally,
a passage narrower than 200 cm (78.74 in.) is
considered a secondary area.
EN
The number of secondary areas managed
depends on the characteristics of the model (See
"Technical Specifi cations").
The minimum passage allowed is 70 cm (27.56
in.) from each edge of the perimeter. The perimeter
wire must be positioned at a distance of (to be
indicated below) from any objects outside the
lawn; therefore, the total passage should be 140
cm (55.12 in.)
If this passage is very long, then it is better for the
passage to be wider than 70 cm (27.56 in.).
During programming, it is necessary to confi gure
the size of the secondary areas as a percentage
of the lawn, and the quickest direction for
reaching it (clockwise or anti-clockwise), as well
as the number of meters of wire needed to reach
the secondary area. See "Programming Mode."
If the aforesaid minimum requirements are not
met and therefore, i.e. an area separated by a
rise or drop with characteristics that cannot be
managed by the robot or a passage (corridor)
narrower than 70 cm (27.56 in.) from perimeter
edge to perimeter edge, this area of the lawn
area is considered a "Closed Area." To mark a
"Closed Area" lay the outgoing and incoming
perimeter wire in the same track at a maximum
distance of 1 cm (0.40 in.). In this case, the
robot is unable to reach the area autonomously
and must be managed as described in the
chapter "Management of Closed Areas." The
management of "Closed Areas" reduces the
square meters that can be managed by the robot
autonomously. It is recommended to use the
"Management of Closed Areas" only for areas
smaller than 900 m2 (9684 sq.ft).
User's manual
flowerbed
20
PRIMARY AREA
corridor with a minimum passage
of 70 cm / 27,56 inc from edge to edge.
SECONDARY AREA
PRIMARY AREA
corridor with a passage
< 70 cm / 27,56 inc.
CLOSED AREA
drain cover
35 cm. / 13,8 inc.
35 cm. / 13,8 inc.
