Kärcher B 110 R Originalbetriebsanleitung Seite 434

‫ﺑﺪء اﻟﺘﺸﻐﻴﻞ‬
‫ﺷﺤﻦ اﻟﺒﻄﺎرﻳﺔ‬
‫اﺳﺘﺨﺪام ﺟﻬﺎز اﻟﺸﺤﻦ ﺑﻄﺮﻳﻘﺔ ﻏﻴﺮ ﺳﻠﻴﻤﺔ‬
‫ﻋﻠﻴﻚ ﻣﺮاﻋﺎة ﺟﻬﺪ اﻟﺸﺒﻜﺔ وﻣﺘﻄﻠﺒﺎت اﻟﺤﻤﺎﻳﺔ ﻋﻠﻰ‬
‫اﺳﺘﺨﺪم ﺟﻬﺎز اﻟﺸﺤﻦ ﻓﻲ اﻟﺄﻣﺎﻛﻦ اﻟﺠﺎﻓﺔ ﻓﻘﻂ‬
.‫واﻟﺘﻲ ﻓﻴﻬﺎ ﺗﻬﻮﻳﺔ ﻛﺎﻓﻴﺔ‬
‫ﺗﻨﺸﺄ ﻏﺎزات ﻗﺎﺑﻠﺔ ﻟﻠﺎﺷﺘﻌﺎل ﻋﻨﺪ ﺷﺤﻦ اﻟﺒﻄﺎرﻳﺔ‬
‫ﻗﻢ ﺑﺸﺤﻦ اﻟﺒﻄﺎرﻳﺎت ﻓﻲ ﻏﺮﻓﺔ ﻣﻨﺎﺳﺒﺔ ﻓﻘﻂ. ﻳﺠﺐ‬
‫أن ﺗﺤﺘﻮي اﻟﻐﺮﻓﺔ ﻋﻠﻰ ﺣﺪ أدﻧﻰ ﻣﻦ اﻟﺤﺠﻢ وﺗﻐﻴﻴﺮ‬
‫اﻟﻬﻮاء ﻣﻊ ﺣﺪ أدﻧﻰ ﻣﻦ ﺗﺪﻓﻖ اﻟﻬﻮاء وﻓﻘﺎ ﻟﻨﻮع‬
.("‫اﻟﺒﻄﺎرﻳﺔ )اﻧﻈﺮ "اﻟﺒﻄﺎرﻳﺎت اﻟﻤﻮﺻﻰ ﺑﻬﺎ‬
‫ﺗﺠ ﻤ ُﻊ ﻏﺎزات ﺧﻄﺮة أﺛﻨﺎء ﻋﻤﻠﻴﺔ اﻟﺸﺤﻦ أﺳﻔﻞ‬
‫ﺣ ﺮ ّك ﺧﺰان اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ اﻟﻰ أﻋﻠﻰ ﻗﺒﻞ ﺷﺤﻦ‬
.‫اﻟﺒﻄﺎرﻳﺎت ﻗﻠﻴﻠﺔ اﻟﺼﻴﺎﻧﺔ‬
.‫ﺳﺎﻋﺔ‬ 15 - 10 ‫ﻳﺒﻠﻎ ﻣﺘﻮﺳﻂ ﻣﺪة اﻟﺸﺤﻦ ﺣﻮاﻟﻲ‬
.‫ﻟﺎ ﻳ ُﺴﻤﺢ ﺑﺎﺳﺘﺨﺪام اﻟﺠﻬﺎز أﺛﻨﺎء ﻋﻤﻠﻴﺔ اﻟﺸﺤﻦ‬
،‫ﻳﺤﺘﻮي اﻟﺠﻬﺎز ﻋﻠﻰ وﺳﻴﻠﺔ ﺣﻤﺎﻳﺔ ﻣﻦ اﻟﺘﻔﺮﻳﻎ اﻟﻜﺎﻣﻞ‬
‫أي أﻧﻪ إذا ﺗﻢ اﻟﻮﺻﻮل إﻟﻰ اﻟﺤﺪ اﻟﺄدﻧﻰ اﻟﻤﺴﻤﻮح ﺑﻪ‬
‫ﻣﻦ اﻟﺴﻌﺔ، ﻟﺬﻟﻚ ﻳﺘﻢ إﻳﻘﺎف ﻣﺤﺮك اﻟﻔﺮاﺷﻲ‬
‫ﻗﻴﺎدة اﻟﺠﻬﺎز ﻣﺒﺎﺷﺮة اﻟﻰ ﺟﻬﺎز اﻟﺸﺤﻦ وﻳﻨﺒﻐﻲ‬
.‫ﺗﺠﻨﺐ اﻟﺄﻣﺎﻛﻦ اﻟﺼﺎﻋﺪة أﺛﻨﺎء ذﻟﻚ‬
‫ﺟﻬﺎز ﺷﺤﻦ ﺧﺎرﺟﻲ‬
‫اﺳﺘﺨﺪام ﺟﻬﺎز ﺷﺤﻦ ﻏﻴﺮ ﻣﻠﺎﺋﻢ‬
‫ﺧﻄﺮ اﻟﺘﻌﺮض ﻟﻠﺄﺿﺮار‬
‫ﻟﺎ ﺗﻮ ﺻ ّﻞ ﺟﻬﺎز اﻟﺸﺤﻦ ﻣﻊ ﻗﺎﺑﺲ اﻟﺒﻄﺎرﻳﺔ ﻣﻦ ﺟﻬﺔ‬
‫اﺳﺘﺨﺪم ﻓﻘﻂ ﺟﻬﺎز ﺷﺤﻦ ﻣﻠﺎﺋﻢ ﻟﻨﻮع اﻟﺒﻄﺎرﻳﺔ‬
‫اﻗﺮأ دﻟﻴﻞ اﻟﺘﺸﻐﻴﻞ ﻣﻦ اﻟﺠﻬﺔ اﻟﺼﺎﻧﻌﺔ ﻟﺠﻬﺎز اﻟﺸﺤﻦ‬
.‫وﻳﺠﺐ ﻋﻠﻴﻚ ﻣﺮاﻋﺎة إرﺷﺎدات اﻟﺴﻠﺎﻣﺔ ﺑﺸﻜ ﻞ ٍ ﺧﺎص‬
‫ﺟﻬﺎز اﻟﺸﺤﻦ‬ ‫ﺳﻌﺔ‬
6,654-436.0 ‫أﻣﺒﻴﺮ‬ 170
‫ﺳﺎﻋﺔ‬
6,654-434.0 ‫أﻣﺒﻴﺮ‬ 180
‫ﺳﺎﻋﺔ‬
6,654-419.0 285Ah
‫ﺧﻄﺮ‬
‫ﺻﻌﻘﺔ ﻛﻬﺮﺑﺎﺋﻴﺔ‬
.‫ﻟﻮﺣﺔ ﻧﻮع اﻟﺠﻬﺎز‬
‫ﺧﻄﺮ اﻟﺎﻧﻔﺠﺎر‬
‫ﺗﻨﺒﻴﻪ‬
‫اﻟﺨﺰان‬
‫ﺧﻄﺮ اﻟﺎﻧﻔﺠﺎر‬
‫إرﺷﺎد‬
.‫واﻟﺘﻮرﺑﻴﻨﺎت‬
1 .
‫ﺗﻨﺒﻴﻪ‬
.‫اﻟﺠﻬﺎز‬
.‫اﻟﻤﺮﻛﺒﺔ ﻓﻘﻂ‬
‫أدﺧﻞ اﻟﻔﻮاﺻﻞ ﺑﻴﻦ اﻟﺒﻄﺎرﻳﺔ واﻟﺠﻬﺎز ﻓﻲ‬
.‫ﻗﻢ ﺑﺘﻮﺻﻴﻞ اﻟﺄﻗﻄﺎب ﺑﻜﺎﺑﻠﺎت اﻟﺘﻮﺻﻴﻞ اﻟﻤﺮﻓﻘﺔ‬
‫ﺑﻄﺎرﻳﺔ‬
‫ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﻛﺎﺑﻞ اﻟﺘﻮﺻﻴﻞ ﺑﺄﻗﻄﺎب اﻟﺒﻄﺎرﻳﺔ اﻟﺘﻲ‬
4,039-352.7
4,039-354.7
‫أﻣﺒﻴﺮ/ﺳﺎﻋﺔ‬
‫، ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﻛﺎﺑﻞ اﻟﺘﻮﺻﻴﻞ ﺑﺎﻟﻘﻄﺐ‬
4,039-353.7
.‫اﻟﺴﺎﻟﺐ ﺑﺎﺳﺘﺨﺪام ﺑﺮﻏﻲ اﻟﻘﻄﺐ اﻟﻤﻌﺰول‬
‫ﺗﻮﺻﻴﻞ ﻗﺎﺑﺲ اﻟﺒﻄﺎرﻳﺔ ﺑﺎﻟﺠﻬﺎز ﻣﻊ ﻗﺎﺑﺲ اﻟﺒﻄﺎرﻳﺔ‬
.‫ﻗﻢ ﺑﺘﺪوﻳﺮ ﺣﺎوﻳﺔ اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ ﻟﻠﺄﻣﺎم وإﻏﻠﺎﻗﻪ‬
‫اﺣﺮص ﻋﻨﺪ ﻓﻚ وﺗﺮﻛﻴﺐ اﻟﺒﻄﺎرﻳﺎت ﻋﻠﻰ وﺿﻊ آﻣﻦ‬
.‫ﺗﺤﺮﻳﺮ ﺧﺰان اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ وﺗﺤﺮﻳﻜﻪ ﻟﻠﺨﻠﻒ‬
‫اﻟﺘﺨﻠﺺ ﻣﻦ اﻟﺒﻄﺎرﻳﺎت اﻟﻤﺴﺘﺨﺪﻣﺔ ﻃﺒﻘﺎ ﻟﻠﻮاﺋﺢ‬
352.7 - 4.039 ،‫أﻣﺒﻴﺮ/ﺳﺎﻋﺔ‬ 170
‫ﻣﻢ‬ 70 × 85 × 310 ‫ﻓﺎﺻﻞ‬
‫ﻣﻢ‬ 30 × 55 × 240 ‫ﻓﺎﺻﻞ‬
354.7 - 4.039 ،‫أﻣﺒﻴﺮ/ﺳﺎﻋﺔ‬ 180
‫ﻣﻢ‬ 70 × 85 × 310 ‫ﻓﺎﺻﻞ‬
353.7 - 4.039 ،‫أﻣﺒﻴﺮ/ﺳﺎﻋﺔ‬ 285
47 × 60 × 345 ‫ﻓﺎﺻﻞ‬
.‫اﻟﻤﻮاﺿﻊ اﻟﻤﻮﺿﺤﺔ ﻓﻲ اﻟﺼﻮرة‬
- .( )‫ﻣﺎ ﺗﺰال ﻓﺎرﻏﺔ )+( و‬
170 ‫ﺑﺎﻟﻨﺴﺒﺔ ﻟﻤﺠﻤﻮﻋﺔ اﻟﺒﻄﺎرﻳﺎت‬
4.039-352.7
.‫ﺑﺎﻟﺒﻄﺎرﻳﺔ‬
‫ﻓﻚ اﻟﺒﻄﺎرﻳﺔ‬
‫ﺗﻨﻮﻳﻪ‬
‫ﻓﻚ وﺗﺮﻛﻴﺐ اﻟﺒﻄﺎرﻳﺎت‬
‫ﺣﺎﻟﺔ ﻏﻴﺮ ﻣﺴﺘﻘﺮة ﻟﻠﻤﺎﻛﻴﻨﺔ‬
.‫ﻟﻠﻤﺎﻛﻴﻨﺔ‬
." 0 " ‫ﺿﺒﻂ ﻣﻔﺘﺎح اﻟﺄﻣﺎن ﻋﻠﻰ اﻟﻮﺿﻊ‬
.‫ﺗﺼﺮﻳﻒ اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ‬
.‫ﺷﺪ ﻗﺎﺑﺲ اﻟﺒﻄﺎرﻳﺔ‬
.‫ﻓﺼﻞ ﻛﺎﺑﻞ اﻟﻘﻄﺐ اﻟﺴﺎﻟﺐ ﻟﻠﺒﻄﺎرﻳﺔ‬
.‫ﻓﺼﻞ اﻟﻜﺎﺑﻞ اﻟﺂﺧﺮ ﻣﻦ اﻟﺒﻄﺎرﻳﺔ‬
.‫إﺧﺮاج اﻟﺒﻄﺎرﻳﺔ‬
.‫اﻟﺴﺎرﻳﺔ‬
‫ﺍﻟﻌﺮﺑﻴﺔ‬
‫ﺗﺮﻛﻴﺐ اﻟﻔﺮش‬
‫ﺗﻢ ﺷﺮح ﻋﻤﻠﻴﺔ ﺗﺮﻛﻴﺐ اﻟﻔﺮش ﻓﻲ ﻓﺼﻞ "أﻋﻤﺎل‬
‫ﺗﺮﻛﻴﺐ ﻛﻤﺮة اﻟﺸﻔﻂ‬
.‫ﺗﺤﺮﻳﻚ ذراﻋﻲ اﻟﺘﺜﺒﻴﺖ إﻟﻰ أﻋﻠﻰ‬
1
2
‫إدﺧﺎل ﻛﻤﺮة اﻟﺸﻔﻂ ﻓﻲ ﻣﻜﺎن ﺗﻌﻠﻴﻖ ﻛﻤﺮة‬
.‫ﺗﺤﺮﻳﻚ ذراﻋﻲ اﻟﺘﺜﺒﻴﺖ إﻟﻰ أﺳﻔﻞ‬
‫ﺑﻄﺎرﻳﺎت‬
‫ﺣﺰم اﻟﺒﻄﺎرﻳﺔ اﻟﻤﻮﺻﻰ ﺑﻬﺎ‬
1
‫ﺗﺪﻓﻖ‬ ‫ﺣﺠﻢ‬
3 3
/ ‫اﻟﻬﻮاء )م‬ *( ‫)م‬
** (‫ﺳﺎﻋﺔ‬
1,0 2,4
1,6 3,8
5,1 12,6
1
4 .
5 .
‫* اﻟﺤﺪ اﻟﺄدﻧﻰ ﻟﺤﺠﻢ ﺣﻴﺰ ﺷﺤﻦ اﻟﺒﻄﺎرﻳﺔ‬
6 .
‫** اﻟﺤﺪ اﻟﺄدﻧﻰ ﻟﺘﻴﺎر اﻟﻬﻮاء ﺑﻴﻦ ﺣﻴﺰ ﺷﺤﻦ اﻟﺒﻄﺎرﻳﺔ‬
‫إرﺷﺎد‬
‫ﺗﺮﻛﻴﺐ وﺗﻮﺻﻴﻞ اﻟﺒﻄﺎرﻳﺔ‬
7 .
‫اﺣﺮص ﻋﻨﺪ ﻓﻚ وﺗﺮﻛﻴﺐ اﻟﺒﻄﺎرﻳﺎت ﻋﻠﻰ وﺿﻊ آﻣﻦ‬
8 .
.‫اﺣﺮص ﻋﻨﺪ ﺗﻮﺻﻴﻞ اﻟﺒﻄﺎرﻳﺔ ﻋﻠﻰ اﻟﺄﻗﻄﺎب اﻟﺼﺤﻴﺤﺔ‬
1 .
.‫اﺷﺤﻦ اﻟﺒﻄﺎرﻳﺎت ﻗﺒﻞ أول ﺗﺸﻐﻴﻞ ﻟﻠﺠﻬﺎز‬
2 .
.‫ﺗﻔﺮﻳﻎ ﺣﺎوﻳﺔ اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ‬
3 .
.‫اﻓﺘﺢ ﺣﺎوﻳﺔ اﻟﻤﻴﺎه اﻟﻤﺘﺴﺨﺔ وﻗﻢ ﺑﺘﺪوﻳﺮﻫﺎ ﻟﻠﺨﻠﻒ‬
4 .
.‫ﺗﺮﻛﻴﺐ اﻟﺒﻄﺎرﻳﺔ ﻓﻲ اﻟﺠﻬﺎز‬
5 .
6 .
7 .
8 .
1 .
."‫اﻟﺼﻴﺎﻧﺔ‬
1 .
‫ﺧﺮﻃﻮم ﺷﻔﻂ‬
1
‫ﺗﻌﻠﻴﻖ ﻛﻤﺮة اﻟﺸﻔﻂ‬
2
‫ﻛﻤﺮة اﻟﺸﻔﻂ‬
3
‫ذراع اﻟﺘﺜﺒﻴﺖ‬
4
2 .
.‫اﻟﺸﻔﻂ‬
3 .
‫رﻗﻢ اﻟﻄﻠﺐ‬ ‫اﻟﺸﺮح‬
- 4,039 ‫أﻣﺒﻴﺮ‬ 170
352.7 ‫ﺳﺎﻋﺔ - ﺑﺪون‬
،‫ﺻﻴﺎﻧﺔ‬
AGM
- 4,039 ‫أﻣﺒﻴﺮ‬ 180
354.7 ‫ﺳﺎﻋﺔ - ﺑﺪون‬
Gel ،‫ﺻﻴﺎﻧﺔ‬
- 4,039 ‫أﻣﺒﻴﺮ‬ 285
353.7 ‫ﺳﺎﻋﺔ - ﺑﺪون‬
،‫ﺻﻴﺎﻧﺔ‬
AGM
‫واﻟﻤﺤﻴﻂ‬
‫ﺗﻨﻮﻳﻪ‬
‫ﻓﻚ وﺗﺮﻛﻴﺐ اﻟﺒﻄﺎرﻳﺎت‬
‫ﺣﺎﻟﺔ ﻏﻴﺮ ﻣﺴﺘﻘﺮة ﻟﻠﻤﺎﻛﻴﻨﺔ‬
.‫ﻟﻠﻤﺎﻛﻴﻨﺔ‬
‫ﺗﻨﺒﻴﻪ‬
‫ﻣﺒﺎدﻟﺔ اﻟﺄﻗﻄﺎب‬
‫ﺗﺪﻣﻴﺮ إﻟﻜﺘﺮوﻧﻴﺎت اﻟﺘﺤﻜﻢ‬
‫ﺗﻨﺒﻴﻪ‬
‫اﻟﺘﻔﺮﻳﻎ اﻟﺘﺎم‬
‫ﺧﻄﺮ اﻟﺘﻌﺮض ﻟﻠﺄﺿﺮار‬
1 .
2 .
3 .
429
