Pulscon LTC51
Bestellinformationen
13.2

Produktstruktur

Hinweis!
In dieser Darstellung werden Varianten, die sich gegenseitig ausschließen, nicht gekennzeich-
net.
Option mit * = auf Anfrage/in Vorbereitung
Gerät
LTC51
Sonde
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
K
X
Prozessanschluss
A51
A52
A61
A62
A81
A82
A91
A92
AA1
AB1
C51
C52
94
Geführtes Füllstandradar
in mm, Stab Ø8 mm, 1.4404/316L
in mm, Seil Ø4 mm, 1.4401/316, max. 150 mm Stutzenhöhe, Zentrierstab
in inch, Seil Ø1/6 in, 1.4401/316, max. 6 in Stutzenhöhe, Zentrierstab
in mm, Koax, 1.4404/316L
in inch, Stab Ø1/3 in, 1.4404/316L
in mm, Stab Ø12 mm, Alloy C
in inch, Stab Ø1/2 in, Alloy C
in mm, Stab Ø12 mm, 1.4404/316L
in inch, Stab Ø1/2 in, 1.4404/316L
in mm, Stab Ø16 mm, 1.4404/316L, 500 mm teilbar
in inch, Stab Ø0,63 in, 1.4404/316L, 20 in teilbar
in mm, Stab Ø16 mm, 1.4404/316L, 1000 mm teilbar
in inch, Stab Ø0,63 in, 1.4404/316L, 40 in teilbar
in mm, Seil Ø4 mm, 1.4401/316, max. 300 mm Stutzenhöhe, Zentrierstab
in inch, Seil Ø1/6 in, 1.4401/316, max. 12 in Stutzenhöhe, Zentrierstab
in inch, Koax, 1.4404/316L
in mm, Koax, Alloy C
in inch, Koax, Alloy C
Sonderausführung
1-1/2 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
1-1/2 in 300 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
2 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
2 in 300 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
3 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
3 in 300 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
4 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
4 in 300 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
6 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
8 in 150 lbs RF, 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
1-1/2 in 150 lbs, Alloy C > 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
1-1/2 in 300 lbs, Alloy C > 1.4401/316/1.4404/316L, Flansch ANSI B16.5 (CRN)
