13.3.12 Ordering spare parts

Please provide the following information when ordering
replacement parts:
• Device type
• Device article number
Spare parts / accessories
Lawnmower blade - article no.:
Battery - Article no:

13.3.13 Service information

With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that the
following parts are required as consumables.
Wearing parts*: Spark plug, air filter, fuel filter, mowing blade,
v-belt, battery, blade, tyres
* may not be included in the scope of supply!

14. Storage

m DANGER!
Risk of fire and explosion!
Storing the product near potential sources of ignition can result
in a fire or an explosion. This leads to severe burns or death.
- Eliminate possible sources of ignition, such as furnaces, hot
water boilers with gas, gas dryers, etc.
NOTE!
Risk of damage!
If the product is not stored properly, the engine can be
damaged.
- Store the product protected against dirt, dust and moisture.

14.1 Storage during extended breaks in operation

Allow the engine to cool down before parking the device in an
enclosed space.
Store the petrol ride-on lawnmower with the tank emptied and
also store the fuel supply in a lockable and well-ventilated area.
Never store the device with petrol in the fuel tank inside a
building in which fuel vapours may come into contact with
naked flames or sparks. If the tank has to be emptied (e.g.
decommissioning before winter break), the fuel tank should
only be emptied outdoors (e.g. empty the tank by running the
combustion engine outdoors).
Store the petrol ride-on lawnmower in a safe condition.
The ignition key (30) must always be removed from the ignition
lock (10) and stored securely to prevent unauthorised or
improper use by children and other persons.
Clean the petrol ride-on lawnmower thoroughly before storing
it (e.g. winter break). Dry grass cuttings and leaves near the
silencer can catch fire. Danger of ignition!
Allow the device to cool down completely before covering it.
20 GB/IE
7911200616
5911235066
Before storage, carry out all necessary maintenance work.
When the petrol ride-on lawnmower is taken out of service for
an extended period of time, before starting work on or near
electrical components, disconnect the battery connection cable
(24) from the engine connection cable (24a). We recommend
removing the battery (16a) and storing it fully charged in a dry
and locked room.
14.1.1 Removing the battery (fig. 9)
1. To do this, disconnect the battery connection cable (24) and
the engine connection cable (24a). (Fig. 9).
2. Then loosen the two screws (16b) from the battery cover
(16) using a Phillips screwdriver (not included in the scope
of delivery).
3. Remove the battery (16a) including the battery cover (16).
Ensure that batteries are secured against unauthorised use (e.g.
by children).
Charge the battery (16a) during the winter 1-2
times to ensure that the full charging capacity is
maintained. Incorrect storage can damage the
battery (16a) and is excluded from the guarantee.
14.2 Drain petrol with a petrol extraction pump
1. Hold a collection container under the hose of the petrol
extraction pump (not included in the scope of delivery).
2. Unscrew and remove the tank cover (17).
3. Push the hose of the petrol suction pump into the fuel tank
and drain the petrol completely using the petrol suction
pump.
4. Re-tighten the tank cover (17).

15. Disposal and recycling

The device is supplied in packaging to avoid transport
damages. This packaging is raw material and can thus be used
again or can be reintegrated into the raw material cycle.
The device and its accessories are made of different materials,
such as metals and plastics. Take defective components to
special waste disposal sites. Check with your specialist dealer
or municipal administration!
The packaging is wholly
environmentally-friendly materials that can be
disposed of at a local recycling centre.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
electrical devices.
composed of
