Group Parameter
LIMIT Source
VAL. 1...4
SwtchDir
Value
OnDelay ms Switch-on delay; when a limit value level is exceeded,
OffDlay ms
4)
PkVal InputMin/
ClearPkV
42
Meaning
Scaling specifications
Output characteristic:
The scale factor for the analog output comes from the input
and output characteristics. If the preset nominal (rated)
value corresponds to the measuring range in kHz, the mini­
mum output voltage to be set is 0.5 V. If settings lead to the
limits being exceeded, an "Analog scaling error" is signaled
(see page 81).
Analog output scaling range, min.: 0.5 V at 100 % of input
measuring range
Analog output scaling range, max.: 10 V at 1 % of input
measuring range
The choice of source for the limit value signal is: Gross, net,
max peak value/min peak value/peak-to-peak
Functions and parameters of the limit values
Hyst
Overshoot
Undershoot
the change only takes effect at the output after a delay
(OnDelay).
Switch-off delay, as for OnDelay
The choice of source for the peak value signal is: Gross, Net
Max
The peak value can be cleared.
LV1, ON
OFF
LV2, ON
24 V
0 V
LV1 ON
24 V
0 V
EXPLANATION OF THE MAIN PARAMETERS
Value
OFF
Value
LV2 ON
Hyst
Hyst
