Fig. 4.4 Amplifier adjustment (continued)
Bus termination resistor
Fig. 4.5 Switch for CAN bus termination resistor (schematic diagram)
MP60, MP60DP
AMPLIFIER SETTINGS WITH DIP SWITCHES
Master
Slave
S14
ON
S10
1 2 3 4 5 6
ON
S10
1 2 3 4 5 6
OFF
ON
Synchronization
Toggle switch for
termination resistor
(see also page 24)
