ENVIRONMENTAL PROTECTION

Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice.

TROUBLE SHOOTING GUIDE

CONDITION
Machine will not start.
Sliding Carriage will
not move.
Left Hand Table Extension
will not deploy.
Blade will not rise or fall.
Blade will not tilt.
Blade Guard does not
adjust automatically.
POSSIBLE CAUSE
Plug removed from outlet
socket or outlet socket
not switched 'on' .
Sliding Carriage Locking
Latch still fully or
partially engaged.
One or both (usually
the rear) of the under-table
locking knobs not
l oosened.
Dual Purpose Rise and
Fall Handle partially engaged
with curved toothed rack.
Tilt Locking Screw
not loosened.
Over -tightened rear fixing
screw and wingnut.
29
ACTION
Replace plug and/or switch
'on' the outlet socket.
Ensure that the Carriage
Locking Latch is completely
disengaged by sliding it
fully to the right.
Ensure that both locking
knobs are sufficiently
loosened. Deploy the table
extension and retighten both
under-table locking knobs.
Ensure that the Handle is
in its outer position. Pull the
Handle out from the machine
slightly to confirm it is deployed
in the outer position.
Loosen the Tilt Locking Screw.
Tilt the blade to the desired
angle and then retighten the
locking screw
Loosen wingnut slightly until
Blade Guard operation is
smooth and satisfactory.
