Changing a procedure
☞ Select the procedure to be changed and press the rotary/push
knob. The "Delete and create" display field will be activated.
☞ Press the rotary/push knob with the "Delete and create" field se-
lected to delete the procedure.
New vacuum and rotation values can now be entered to define a
new step in procedure.
Vacuum
☞ Turn the rotary/push knob to the right/left to select "Vacuum" from
the on-screen options.
☞ Press the rotary/push knob.
☞ Turn the rotary/push knob to the right/left to enter a value.
☞ Press the rotary/push knob.
Duration
☞ Turn the rotary/push knob to the right/left to select "Duration"
from the on-screen options.
☞ Press the rotary/push knob.
☞ Turn the rotary/push knob to the right/left to enter a value.
☞ Press the rotary/push knob. This will define a new step in the pro-
cedure with the pair of values vacuum-duration and add it to the
procedure. The diagram will be updated.
Rotation
☞ Turn the rotary/push knob to the right/left to select "Rotation" from
the on-screen options.
☞ Press the rotary/push knob.
☞ Turn the rotary/push knob to the right/left to enter a value.
☞ Press the rotary/push knob.
Duration
☞ Turn the rotary/push knob to the right/left to select "Duration"
from the on-screen options.
☞ Press the rotary/push knob.
☞ Turn the rotary/push knob to the right/left to enter a value.
☞ Press the rotary/push knob. This will define a new step in the pro-
cedure with the pair of values rotation-duration and add it to the
procedure. The diagram will be updated.
The vacuum-duration and rotation-duration steps can be repeated a
maximum of ten times.
SET key: Exit menu, store the newly created procedure and activate
it as the current procedure.
ESC key: Exit menu and reset all changes.
042009
Stopping user-defined distillation
The user-defined distillation will stop automatically once all steps in
the currently active procedure have been completed. It is also pos-
sible to stop the process manually by pressing the rotary/push
knob with the "Stop" display field selected.
Stand-by operation
☞ Press the "Power" button.
The device will enter stand-by.
☞ Press the "Power" button again.
The screen will display "Start" to indicate that the device is ready
for use again.
