Always clamp the workpiece to a rigid support such as a bench
or saw horse whenever possible. (10.2>)
(5.4)

ThE ON/OFF TrIGGEr SwITCh

This machine is equipped with
a safety start trigger switch. (Fig. 8)
To start the tool:
• Push in the safety lock button on the side of the
handle with your thumb.
• Depress the main trigger switch to start the motor.
wArNING: Never start the saw with the cutting edge
of the saw blade in contact with the workpiece surface.
(10.3)

CuTTING AdVICE

wArNING: The operator should wear all relevant PPE (Personal
Protection Equipment) necessary for the job at hand. This
could include safety glasses, dust masks, safety shoes etc. The
operator should always be aware of the position and routing of
the power cable.
(10.4)
• Do not force the machine.
• Allow the speed of the saw blade do the work. Cutting
performance will not be improved by applying excessive
pressure to the machine, and blade life will be reduced.
• When using the parallel edge guide, ensure that it is parallel
with the blade. The blade and/or motor could become
damaged if the machine is used with an incorrectly adjusted
parallel edge guide.
• Place the front edge of sole plate squarely
on the workpiece, ensuring that the saw blade is not in
contact with the workpiece, before starting the motor.
• When starting a cut, sight the cutting line with the line of
cut guide, taking care to introduce the blade to the material
slowly, so as not to damage its teeth.
Note: Two (2) line of cut guides (for 0
are positioned on the front edge of the sole plate.
• Use both hands to move the saw forwards through the
workpiece.
• Apply smooth, constant pressure to move the saw forwards
through the workpiece.
When a cut has been completed release the ON/OFF trigger
and 45 bevel angle only)
0 0
15
Fig. 8
