SCHUNK PGN-plus 40 Montage- Und Betriebsanleitung Seite 37

Montage- und Betriebsanleitung für
2-Finger-Parallelgreifer Type PGN-plus
Ident-Nr.
Type
Id.-No.
Anschlag
für MMS-P 9949504
Stop for MMS-P
3.0
PGN-plus
Type
PGN-plus 40
PGN-plus 40 AS
PGN-plus 40 IS
PGN-plus 50-1
PGN-plus 50-1 AS
PGN-plus 50-1 IS
PGN-plus 64-1
PGN-plus 64-1 AS
PGN-plus 64-1 IS
PGN-plus 80-1
PGN-plus 80- 1 AS
PGN-plus 80-1 IS
PGN-plus 100-1
PGN-plus 100-1 AS
PGN-plus mit Kraftverstärkungszylinder (KVZ) / PGN-plus with power booster cylinder (KVZ)
Type
PGN-plus 40/1-KVZ
PGN-plus 40/1 AS-KVZ
PGN-plus 40/1 IS-KVZ
PGN-plus 50/1-KVZ
PGN-plus 50/1 AS-KVZ
PGN-plus 50/1 IS-KVZ
PGN-plus 64/1-KVZ
PGN-plus 64/1 AS-KVZ
PGN-plus 64/1 IS-KVZ
PGN-plus 80/1-KVZ
PGN-plus 80/1 AS-KVZ
PGN-plus 80/1 IS-KVZ
A
Max.
10 Ncm
Maß/Dim. l Maß/Dim. l
1 2
6.0 14.9
10.0 18.9
15.0 23.9
6.5 15.4
11.9 20.8
22.5 31.4
13.5 22.4
10.3 19.2
31.5 40.4
17.1 26.0
13.5 22.4
35.1 44.0
18.8 27.7
11.0 19.9
Maß/Dim. l Maß/Dim. l
1 2
6.0 14.9
15.0 23.9
15.0 23.9
21.8 30.7
37.8 46.7
37.8 46.7
32.5 41.4
50.5 59.4
50.5 59.4
39.6 48.5
57.6 66.5
57.6 66.5
37
Assembly and Operating Manual for
2-Finger Parallel Gripper Type PGN-plus
/10/
/11/
Type
PGN-plus 100-1 IS
PGN-plus 125-1
PGN-plus 125-1 AS
PGN-plus 125-1 IS
PGN-plus 160-1
PGN-plus 160-1 AS
PGN-plus 160-1 IS
PGN-plus 200-1
PGN-plus 200-1 AS
PGN-plus 200-1 IS
PGN-plus 240-1
PGN-plus 240-1 AS
PGN-plus 240-1 IS
Type
PGN-plus 100/1-KVZ
PGN-plus 100/1 AS-KVZ
PGN-plus 100/1 IS-KVZ
PGN-plus 125/1-KVZ
PGN-plus 125/1 AS-KVZ
PGN-plus 125/1 IS-KVZ
PGN-plus 160/1-KVZ
PGN-plus 160/1 AS-KVZ
PGN-plus 160/1 IS-KVZ
PGN-plus 200/1-KVZ
PGN-plus 200/1 AS-KVZ
PGN-plus 200/1 IS-KVZ
A
Maß/Dim. l Maß/Dim. l
1 2
44.8 53.7
14.1 23.0
50.7 59.6
44.0 52.9
22.5 31.4
63.0 71.9
62.5 71.4
28.5 37.4
78.5 87.4
78.5 87.4
33.5 42.4
91.0 99.9
90.0 98.9
Maß/Dim. l Maß/Dim. l
1 2
45.3 54.2
71.3 80.2
71.3 80.2
46.6 55.5
76.5 85.4
76.5 85.4
60.0 68.9
100.0 108.9
100.0 108.9
73.5 82.4
123.5 132.4
123.5 132.4
