15 Technical data

CDS installation type (Cable Distribution
System). The installation is type TNV-1, do
not connect it to SELV circuits.
CAUTION! In order to reduce the risk of fire,
only use cable with sections greater than or
equal to 0.13mm² (AWG 26).

15.1 General

Constructed from aluminium and tecnopolymer
Epoxypolyester powder painting, RAL9002 colour
Easy installation thanks to the self-centring connector
Zero backlash
Quick configuration and setup
Dynamic positioning control system

15.2 Mechanical

Cable glands: 2xM16, 2xM12
Horizontal rotation: continuous
Vertical rotation: From -90° a +90°
Horizontal speed (variable): From 0.1°/s a 200°/s
Tilt speed (variable): From 0.1°/s a 200°/s
Preset accuracy: 0.05°
Unit weight: 12.5kg (28lb) (13kg / 28.7lb with LED
illuminator)
MNVCUCZ_1511_EN

15.3 Electrical/Video

Power supply/Current consumption:
• 230Vac, 0.4A, 50/60Hz
• 24Vac, 4A, 50/60Hz
• 120Vac, 0.8A, 50/60Hz
Power consumption:
• 40W: P&T stopped, heating switched off
• 60W: P&T in motion, heating switched off
• 125W: peak at start-up, heating switched on
Power consumption with illuminator on:
• 55W, P&T stopped, heating switched off
• 75W, P&T in motion, heating switched off
• 140W, peak at start-up, heating switched on
Input cables size: AWG 16-AWG 19
Dimensions of signal cables: AWG 16-AWG 30
Video line: coaxial cable (1Vpp, 75Ohm)
Functions: Autopan, Preset, Patrol, Tour (maximum 3),
Autoflip
Maximum number of presets for protocol
• AMERICAN DYNAMICS: 95*
• ERNITEC: 250
• PANASONIC: 250
• PELCO D: 99*
• VIDEOTEC MACRO: 250
*250, from OSD only (On Screen Display)
16-characters string for zone and preset titling
I/O alarm card
• Alarm inputs: 6
• Relay outputs: 2 (2A, 30Vac/60Vdc max)
