GB iveo initial operation/Setting by radio

6.4. Functions in service mode (setting by using a transmitter)

In order to carry out the following settings, the motor has to be put into service mode
by disconnecting it from the mains supply in a special way.
Consider the following:
• Transmitter programmation has to be finished before service mode can be exe-
cuted.
• Put only the motor which is to be set into service mode.
• The motor remains in service mode for 4 minutes.
• In order to leave the service mode just drive the motor up or down.
Fuse/Hirschmann plug
3 s 3 s 3 s
The motor confirms the service mode by a brief up and down moving.

6.5. Adjusting the end limits by using the transmitter

Setup-mode can only be finished by programming both end positions. The transmitter
assignment is not affected by this. When setting the end positions, the motor is in the
normal operating state again.
Put the motor into service mode by disconnecting it. Press the STOP button of an
assigned transmitter for 6 (manual setup-mode)/9 (automatic setup-mode) seconds to
return the motor to setting mode (wait until the transmitter indicator flashes twice/three
times). Then set the end positions as described in the grey sections for items 6.1.1. to
6.1.3.
Fuse/Hirschmann plug
3 s 3 s 3 s
Assigned transmitter
STOP
6 s
or
STOP
9 s
64
Set the end positions as
de scribed in the grey sections for
items 6.1.2. and 6.1.3.
Set the end positions as
de scribed in the grey sections for
item 6.1.1.
