commeo initial operation/Setting by radio
Note for settings under point 5.2.: The motor must be selected for this setting with
a transmitter in SELECT mode (Status LED flashes slowly in orange). After completing
the setting, the motor is still selected (see point 5.).
5.2.1. Semi-automatic setup-mode, deletion and semi-automatic setting of the
upper end positions
in operation bottom position, top stop/release
When the movement is interrupted twice during operation, the system is in semi-
automatic setup-mode. The drive will only find the upper end limit automatically.
Important: A limit stop for the upper end limit is necessary!
First the lower end limit has to be run-up to. From there move against the upper limit
stop without interruption, until the motor is automatically switched off.
Operation
9 s
or
Drive
Press the STOP button of the transmitter for 9 seconds.
Both limit positions already set will be deleted.
Note: Not required for the initial installation or after resetting
to factory defaults.
Move the motor with the UP or DOWN button downwards
to the requested lower end limit.
Run against the limit stop at the top without stopping; the
motor stops automatically. The correct direction of rotation
assignment has been made.
Perform a test run: The drive moves up against the limit stop
and relieves shortly.
Note: The transmitter may not yet have been programmed.
See point 5.2.4. to program a transmitter.
