contents. All connections must therefore be checked carefully to
ensure that they are tight.
Ensure that all seals are correctly seated to avoid escape of water
due to leakage.
Familiarise yourself with all local conditions, e.g. water connections
and shut-off device, prior to installation.
This product is only suitable for use in rooms with temperature
above 0 °C. In case of potential frost, cut off the water supply and
drain the taps.

Assembly

Note: Familiarise yourself with the product prior to assembly. Carefully
read the following assembly instructions and safety advice. In the event
of incorrect installation, all warranty claims – particularly in relation to
subsequent damage – are excluded.
CAUTION! Before you start installation turn off the water supply
at the mains. Otherwise there is a danger of injury and / or dam-
age to the product.
CAUTION! Do not twist or strain the connection hoses
Note: This step requires a slot screwdriver and a 12 mm open-end
spanner.
Follow these steps:
CAUTION! Be sure to only fasten the connecting hoses
tight (see Fig. A). Do not use pliers or a wrench. Otherwise the
product could be damaged.
Screw the two connecting hoses
boreholes in the fitting body
Using a slot screwdriver tighten the threaded bolt
into the fitting body
hand tight into the designated
16
(see Fig. A).
8
and remove the fastening nut
8
.
16
hand
16
all the way
14
.
15
