AEC-PANEL19 - Installation manual
NOTICE!
Figure 3 is a schematic diagram of interconnections within the
i
19" frame, and does not reflect the actual positioning of devices
on the mounting plate.
NOTICE!
This section describes battery connections in 24V-mode. If you
i
wish to run the AMC2 in 12V-mode, please follow Section 12V-
mode variants, Page 11.
CAUTION!
!
Connect all devices in the order described below before
connecting voltage.
1.
2.
3.
4.
5.
Bosch Sicherheitssysteme GmbH
Mount the AMC2 on the rail (6) on the front of the
mounting plate (X), to the right of the battery bracket (3),
befindet. The rail on the rear (Y) is available for a second
AMC device.
Mount the power supply using the three screws G3 in the 3
screw sockets (2) at the rear(Y)
Stand the battery/-ies in the bracket (3).
Connecting the PBC-60 power supply to the AMC2 with
cable set A:
a.
Insert connector A1 into the 7-pole socket of the
AMC2 marked POWER
b.
Clip the grounding cable A4 under the fixing screw 5
on the mounting plate.
c.
Pass the ends A2 and A3 of the cable set through the
lower opening 4 to the rear side of the mounting
plate.
d.
At the PBC-60 power supply connect the A3 plug to
the socket marked DC, and the A2 plug to the socket
marked OK.
Connecting battery monitoring using cable set B:
a.
Connect the B1 plug to the position marked BAT on
the power supply.
b.
Pass the rest of the cable ends through the upper
opening 4 to the front side of the mounting plate.
c.
Connect the B2b plug (red) to the positive terminal of
the first battery.
d.
Using cable C connect the negative terminal of the
first battery to the positive terminal of the second
battery.
F.01U.097.256 | V 1.1 | 2008.12
