asseMBly
traMpoline
► Take the rear frame element, and slide
the trampolinemesh webbing cloth into
the groove – the end containingpaddle
fixing brackets must point forward to-
wards the bows.
► Slide both side frame elements from the
front onto the trampoline cloth. - the D-
rings must show upward in direction to
the bows.
notice: punched markings on the un-
derside of the frame elements indicate
numbers 1-4. correctly assembled the
frame numbers match (1-1, 2-2, 3-3, 4-4)
► Slot the frame side elements onto the
rear element and pull the trampoline
cloth taut in forward direction.
20
► Push the insert-stubs of the forward
frame element into the two side frame
elements.
► Erect the fame assembly and connect the
snap-buckles of the trampoline cloth.
► Tighten the trampoline cloth by pulling
the straps taut.
attention: tension of the trampoline cloth
ought to be checked frequently. if need be,
re-tension.
► Fix the tensioning stays to the rear frame
element.
