Package contents

1 cordless pruner PAHE 20-Li A1
1 shoulder strap
1 blade guard
1 Blade
1 saw chain
100 ml organic chain oil
1 assembly tool
1 operating instructions

Technical data

Cordless pruner PAHE 20-Li A1
Rated voltage
Max. rotational speed 2500 min
No-load speed
Weight (without battery, cutting tool
and strap)
Oil tank volume
Cut length
Blade
Saw chain
Use only the following battery to
operate the cordless tool PAP 20 A3*
Type
Rated voltage
Capacity
Cells
Use only the following high-speed
battery charger to charge the cordless tool
PLG 20 A2*
INPUT
Rated voltage
Power consumption
Fuse (internal)
OUTPUT
Rated voltage
Charging current
Charging time
Protection class
* BATTERY AND CHARGER NOT INCLUDED IN
DELIVERY
PAHE 20-Li A1
20 V (direct current)
-1
max. 5 m/s
approx. 2.6 kg
65 cm 3
approx. 200 mm
8" Oregon 080NDEA318
Oregon 91P033X
LITHIUM ION
20 V (direct current)
4000 mAh/80 Wh
10
230–240 V ∼, 50 Hz
(alternating current)
85 W
T3.15A
3.15 A
21.5 V (direct current)
3.5 A
approx. 80 min
II / (double shielded)
Noise and vibration data
Measured values for noise determined in accord-
ance with EN ISO 22868. The A-rated noise level
of the power tool is typically as follows:
Sound pressure level
Uncertainty
Sound power level
Uncertainty
Wear ear protection!
Vibration values (vector total of three directions)
determined in accordance with EN ISO 22867:
Vibration
Uncertainty K =
WARNING!
► Depending on the use and the activities to
be performed, the sound pressure level must
be reduced to a level that does not adversely
affect the health of the operator. The sound
pressure level at the workplace may exceed
80 dB (A). In this case, sound insulation
measures are required for the operator (e.g.
wearing hearing protection).
► Also reduce the risk of vibration, e.g. the
risk of white-finger disease due to frequent
breaks in work where like rubbing their palms
together! Translated with www.DeepL.com/
Translator (free version)
NOTE
► The vibration level specified in these instruc-
tions has been measured according to a
standardized measurement procedure and
can be used for equipment comparison. The
vibration emission value given may also be
used for an initial assessment of exposure.
L = 88 dB (A)
pA
K = 3 dB
pA
L = 106 dB (A)
WA
K = 3 dB
WA
< 2.5 m/s 2
1.5 m/s 2
