Ersatzteile - Cannondale RUSH 29 Handbuch

ERSatZtEIlE

4
9
Loctite 242 (blue)
5 Nm (44 InLbs)
9
HINTERES
SCHALTAUGE
KP048/
Loctite 242 (blue)
1.1 Nm (9.7 InLbs)
SCHWINGE
Secure with
3 mm zip tie.
NO. (QTY) CODE
KP071/
KP113/STD
LK, 4 (2)
KP113/SM
KP048/
1A502/BLK
KP077/
LINK INFO:
KIT DIMENSION
A ' B'
KP113/STD 101 mm 29.5 mm
KP113/SM 82 mm 24.3 mm
10 10
3
SCHWINGENGELENK
STOSSDÄMPFER-
VERBINDUNGSGELENK
Loctite 242 (blue)
5 Nm (44 InLbs)
SATTELSTREBE
7
KETTENSTREBENSCHUTZ
1A502/BLK
11
KP077/
STOSSDÄMPFERVERBINDUNG
DESCRIPTION
KIT, HWARE, SHOCK MOUNTING, RZ
KIT, LINK, RZ 120, BLK, M-X,
Need - KP074/
KIT, LINK, RZ 120, BLK, P-S,
Need - KP074/
KIT, DER. HANGER; SINGLE SIDED 3
CHAINSTAY PROTECTOR, RZ
KIT, CH. STAY PROTECT-RZ
FRAME SIZE
SM MD LG XL
X X
X
X
4
7
A'
LK
B'
4
8
7
12
NO. (QTY)
3, 5, 6(2) 7(6),
8(2), 9(2)
11, 13(2), 15
12
4(6)
J
X
5
Loctite 242 (blue)
5 Nm (44 InLbs)
STOSSDÄMPFERBEFESTIGUNGS
SCHRAUBEN
KP071/
7
30 mm
30 mm
12 Nm, 106 In Lbs
Loctite™ 242 (blue)
15
12
SCHWINGENHAUPT-
LAGERMUTTER
12 Nm, 106 In Lbs
Loctite™ 242 (blue)
LAGERABDECKSCHEIBEN
Glatte Seite nach innen
CODE DESCRIPTION
KP072/BLK KIT, LINK, HWARE, RZ BLK
KP072/RED KIT, LINK, HWARE, RZ, RED
KP070/BLK KIT, PIVOT SWINGARM, RZ, BLK
KP070/RED KIT, PIVOT SWINGARM, RZ, RED
KIT, BEARING, 1 #6902-2RS
KB61902/
15 (I.D.) x 28 (O.D.) x17 (W)
KIT, BEARING, 6 #6800-2RS
KP073/ 10 (I.D.) x 19 (O.D.) x 5(W),
Need - KP074/
KP074/ KIT, LOCTITE 638, 10 ML
