Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
1. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
2. Description
1 Power cable
2 Locking button
3 On/Off switch
4 Knurled screw for regulating the speed
5 Inspection guard
6 Saw blade
7 Guide roller
8 Adjustable base
9 Selector switch for pendulum action
10 Adapter for chip extractor
11 Allen key
3. Use
The jigsaw is designed for sawing wood, iron, non-
ferrous metals and plastics using the appropriate
saw blades.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Starting up
Instant response operation (Figure 1)
Switching on:
Press the On/Off switch
Switching off:
Release the On/Off switch
6
08.12.2006
Continuous operation
Switching on:
Press the On/Off switch, keep pres
sed and lock with the locking button
Switching off:
Press the On/Off switch and release
Electronic speed control setting (Figure 1)
Using the knurled screw on the On/Off switch you
can pre-set any speed. Turn the knurled screw in
PLUS direction for a higher speed and turn it in
MINUS direction for a lower speed. The ideal cutting
rate depends on the specific material and working
conditions.
The general rules for tool speed in cutting operations
apply.
Setting the pendulum action (Figure 1)
Position 0: No pendulum aktion
Position 1: Slight pendulum action
Position 2: Intensive pendulum action
Changing the saw blade (Figure 2)
Switch off the jigsaw and remove the plug from the
power socket before changing the blade or carrying
out any other work on the jigsaw.
Use the supplied hexagon-socket spanner to undo
the two screws (1/2) on the ram (Figure 2). Slide the
saw blade into the guide slot and up to the stop bet-
ween the piston rod and the retention clip. Use the
supplied hexagon-socket spanner to tighten the two
screws. The teeth of the saw blade must face in
cutting direction. Make sure that the saw blade sits
properly in the guide slot of the ram and roller.
Adjusting the base (Figure 3)
For mitre and bevel cuts you can swivel the base by
up to 45° in either direction after undoing the two
screws (a) on the bottom. The angles 15°, 30° and
45° are marked but you can adjust the saw to any
angle between these markings as required.
To adjust the cutting angle, undo the two screws (a)
until you can just about move the blade. Adjust to the
required angle and re-tighten the two screws.
Dust extraction (Figure 1)
The jigsaw is equipped with a dust extractor socket.
Mount the adapter on the jigsaw and fix it in place by
twisting. Any vacuum cleaner can be connected to
the socket at the rear of the jigsaw. If you require a
special adapter, please contact the manufacturer of
your vacuum cleaner.
