HONDA
G300/G400
• CHOKE LINKAGE
QI CHOKE LEVER
® CHOKE STAY
b.
INSPECTION
• FLOAT HEIGHT
W3
AIR CLEANER ELBOW
I2
LINKAGE
REASSEMBLY:
• Hook one end through the hole
in choke lever.
• Make sure the choke valve opens
fully when linkage is pushed all
the way in.
Place the carburetor in an upright position and measure the distance
between the float top and carburetor body when the float lust
contacts the float valve.
Standard float height
G300
8.2 mm (0.32 in)
G400
8.6 mm (0.34 in)
• if the height is out of specification, re place the float.
0
0
0
0
0
0
0
72
Date of Issue: Nov., 1978
© HONDA MOTOR CO.,LTD.
