2. Design and function / 3. Safety
In the standard version the thermocouples are manufactured without process
connections. Fastening elements such as a union screw, a compression fitting, or a
spring-loaded or customer-specific hold down device can be attached and are available
as options.

2.2 Scope of delivery

Cross-check scope of delivery with delivery note.

3. Safety

3.1 Explanation of symbols

WARNING!
... indicates a potentially dangerous situation that can result in serious
injury or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in light injuries
or damage to property or the environment, if not avoided.
DANGER!
... identifies hazards caused by electrical power. Should the safety
instructions not be observed, there is a risk of serious or fatal injury.
WARNING!
... indicates a potentially dangerous situation that can result in burns,
caused by hot surfaces or liquids, if not avoided.
Information
... points out useful tips, recommendations and information for efficient
and trouble-free operation.

3.2 Intended use

The thermocouples described here are suitable for temperature measurement in the
plastics / rubber moulding, hot runner and injection moulding industry. Depending
on design, they can be mounted directly into the process or within a bored hole. The
design of the bored hole can be selected as desired, but the operational process data
(temperature, pressure, density and flow rate) must be taken into account.
The instrument is not permitted to be used in hazardous areas!
WIKA operating instructions model TC46
