E N G L I S H
Tool weight.
DATE CODE POSITION (FIG. A)
The Date Code, which also includes the year of
manufacture, is printed into the housing.
Example:
2010 XX XX
Year of Manufacture
Package contents
The package contains:
1 Nailer
1 Safety glasses
1 Instruction manual
1 Exploded drawing
● Check for damage to the tool, parts or
accessories which may have occurred during
transport.
● Take the time to thoroughly read and
understand this manual prior to operation.
Description (fi g. A)
Your nailer D51180 has been designed for driving
fasteners into wooden workpieces.
1 Contact trip
2 Nail guide
3 Air fi tting

ASSEMBLY AND ADJUSTMENT

Air fi tting (fi g. A)
These tools have a standard 1/4" pipe thread for
the air fi tting (3).
1. Wrap the male end of the fi tting with Tefl on tape
to prevent air leaks.
2. Screw the fi tting into the end cap and tighten
fi rmly.
Fitting the upholstery (fi g. B)
The upholstery (4) ensures a safe and comfortable
grip of the tool in operation.
1. Place the ring (5) over the nail guide (2) as shown.
2. Draw the upholstery over the top of the housing.
3. Loop the strips (6) through the ring and click the
press buttons in place.
20
4. Wrap the remaining strips around the tool and
click the press buttons in place.
WARNING: Check that the upholstery
is placed correctly over the tool. The
ring has to be secured by the loops
correctly.

OPERATION

Instructions for Use
WARNING:
● Always observe the safety instructions
and applicable regulations.
● Avoid longer lasting static muscle
tension of hands and arms, e.g. during
overhead work.
● Avoid long-lasting work processes and
unbalanced load for the body without
adequate breaks.
Proper Hand Position (fi g. C)
WARNING: To reduce the risk of serious
personal injury, ALWAYS use proper
hand position as shown.
WARNING: To reduce the risk of serious
personal injury, ALWAYS hold securely in
anticipation of a sudden reaction.
Proper hand position requires holding the nailer in the
palm of your hand, placing your index, middle and
ring fingers behind the loop (7) at the back and your
thumb and little finger in the loops (8) at the sides.
Preparing the tool (fi g. A)
1. Drain all condensation from the air compressor
tanks and hoses.
2. Lubricate the tool. See "Maintenance".
3. Check that there are no objects inside the nail
guide (2).
4. Check if the contact trip (1) can move freely.
WARNING: Do not use the tool if the
contact trip cannot move freely.
5. Check that the pressure of the air supply is
within the rated pressure range as stated in
the technical data. Be sure that the maximum
recommended operating pressure will not be
exceeded more than 10%.
