5.2 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
, , ... Series of steps
1. 2. 3.
6

Tools list

Open-ended wrench
10 mm, 13 mm
7

Information on replacing the sensor

If the plug is disconnected from the sensor, a permanent sensor check is performed by
the transmitter.
For detailed information on troubleshooting and diagnostics, see the "Diagnostics and
troubleshooting" section of the Operating Instructions for the device.
8

Mounting the sensor

Prosonic Flow P, W
WARNING
L
Risk of injury when mounting the sensors and strapping bands!
‣
Due to the increased risk of cuts, wear suitable gloves and protective goggles.
8
6 mm, 8 mm
PZ2
