Before first Use

Unpack the wet grinder and check all parts for any damage in transit. Dispose
of packaging materials or store it out of reach of children. Plastic bags etc.
may become a deadly toy for children.

Intended Use

The machine has been designed for grinding and sharpening tools.
Processing of other materials is not allowed.
The machine must be in perfect working condition for use.
The intended use also includes an operation following the operating
instructions.
Any use beyond these parameters (different media, applying force) or any
changes (reconstruction, no original accessory) can lead to serious risks and
is regarded as use that is contrary to the intended purpose. The operator is
liable for any damage caused by improper use.

Assembling the Grinder

The grinding wheels must be attached to the unit after delivery.
1. The leather honing wheel (6) is attached to the right hand side of the shaft.
The locking pieces on the wheel and the shaft must engage with each other.
2. Secure the wheel with a washer and the included plastic knob. Turn the knob
clockwise to tighten it.
3. Slide the grinding wheel (4) over the left hand side end of the shaft and
secure it with the included nut. Please keep in mind that the nut has left hand
threads.
4. Turn the nut counter clockwise to tighten it. Slide the water tank (5) under the
wheel and hook it into the slots in the housing.
5. Before using the leather wheel for the first time, apply a thin coat of polishing
compound to the leather surface.
The tool support (2) can be installed horizontally or vertically as desired.
6. Before operation, fill the water tank with water up to the max mark. If the
stone absorbs water, refill the tank until the stone is saturated with water.

The Tool Support

Insert the tool support into the mounting holes and secure it with the turn knobs.
The tool support can be installed either horizontally or vertically and facing to the
left or to the right.
