Source de
Plage
tension,
-199,9 mV
Continue
de +199,9 mV
L'impédance de connexion de l'appareil de mesure connecté ne
doit pas dépasser 1 kOhm.
Source de
19,99 mA
courant continu 24,0 mA
Impédance de connexion jusqu'à 500 Ohm sur une plage de 0 à
19,99 mA
Impédance de connexion jusqu'à 400 Ohm sur une plage de 20
mA à 24,0 mA
Mesure de
19,99 mA
courant continu 24,0 mA
Source de cou- 19,99 mA
rant continu,
24,0 mA
boucle à 2
conducteurs
Tension de sortie 12 VCC ±2 V dans la boucle; mesure du courant
de boucle
Attention !
Un dépassement du maximum d'entrée autorisé
et/ou un court-circuit de l'impédance de source peut
conduire à une détérioration de l'appareil.
52
Exactitude
Définition
±(0,25%+1dgt
0,1 mV
±(0,25%+1dgt)
0,01 mA
±(0,50%+1dgt)
0,1 mA
±(0,25%+1dgt)
0,01 mA
±(0,50%+1dgt)
0,1 mA
±(0,25%+1dgt)
0,01 mA
±(0,50%+1dgt)
0,1 mA
Introduction
Dear customer,
By purchasing the Current Calibrator CC - 421 you have acquired a
high-precision calibration tool for you measurement device(s) desi-
gned according to the state of the art. The current source can sup-
ply up to 24 mA max. at 400 ohm. DC current measurement up to 24
mADC and loop current measurements also up to 24 mADC can be
performed with the 2-conductor loop being supplied with 12 VDC
from the device. The current calibrator can also be applied as DC
voltage source from –199.9 to +199.9 mVDC.
The current calibrator was designed according to EN 610610 – 1
(= DIN VDE 0411 / Part 1). The measurement device is EMC-tested
and thus corresponds to the requirements of the relevant national
and European guidelines. Conformity has been proved; the rele-
vant documents are in the possession of the manufacturer.
To preserve this condition and to enable safe operation, you as the
user must observe these operating instructions!
In case of questions, consult our technical
information service
Germany: Tel. 0180/5 31 21 16 or 09604/40 88 47
Fax 09604/40 88 44
e-mail: tkb@conrad.de
Mon - Fri 8.00 to 18.00
Austria: Tel. 0 72 42/20 30 60 · Fax 0 72 42/20 30 66
e-mail: support@conrad.at
Mon - Thu 8.00 to 17.00
Fri. 8.00 to 14.00
Switzerland: Tel. 0848/80 12 88 · Fax 0848/80 12 89
e-mail: support@conrad.ch
Mon - Thu 8.00 to 12.00, 13.00 to 17.00
Fri 8.00 to 12.00
