Technical Instructions
Fig. 18 Dismantling of ball bearings
No. 4080 0302 00
Fig.No.10 –
Ref.No. 9
Fig. 19 Inspection of motor
(R) = To be replaced
at every overhaul
Fig. 20 Assembly of motor
No. : 4080 0013 00
Check the clearance : 0.02 – 0.03 mm
Fig.No.10 –
Ref.No. 2
Fig.No.10 –
Ref.No. 3
No. : 4080 0321 00
40
(R)
No. : 4080 0567 02
Atlas Copco Tools – No. 9836 1945 01
No. 4080 0182 10
(R)
No. : 4080 0567 01
Fig.No.10 –
Ref.No. 10
Fig.No.10 –
Ref.No. 9
No. : 4080 0321 00
181 / 75
No. : 4080 0182 09
No. : 4080 0182 10
181 x 30
(R)
181 x 100
Fig.No.10 –
Ref.No. 9 + 10
