Emissions; Steady And Follow Rest; Machine Dimensions; Working Area - Optimum OPTiturn TH4610D Betriebsanleitung

Quill diameter [mm]
Spindle stroke [mm]
Taper in the quill
2.8

Steady and follow rest

Steady rest passage min. - max. [mm]
Follow rest passage min. - max. [mm]
2.9

Machine dimensions

Installation plan
Net weight [kg]
2.10

Working area

2.11

Dimensions and weight with packaging

Height [mm]
Length [mm]
Depth [mm]
Total weight [kg]
2.12

Environmental conditions

Temperature
Relative humidity
2.13

Operating material

Headstock, Mobilgear 627 or a
comparable oil;
Apron gearbox, Mobilgear 629 or a
comparable oil;
Feed gear, Mobilgear 629 or a
comparable oil;
Bare steel parts and lubricating nipple,
Coolant equipment
Commercially
cooling agent / lubricants
approximate values
2.14

Emissions

The generation of noise emitted by the lathe is 90 dB(A) at idle.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Version 1.0.6 - 2022-5-17
TH4610

Installation plan TH4610 | TH4615 | TH4620 on page 139
1645
Keep a work area of at least one metre around the machine free for
operation and maintenance.
1650
2280
1150
1910
Acid-free lubricating oil
Translation of original instruction
TH4615 TH4620
60
130
MT4
25 - 178
19 - 114
1810 1965
1650 1650
2800 3400
1150 1150
2115 2295
5 - 35 °C
25 - 80 %
20
2.3
7.6
20 litres
TH4610 | TH4615 | TH4620 EN
