Technical Data - Siko MS500 Originalmontageanleitung

MS500
22

Technical data

Mechanical data
Housing
Sensor/band reading dis-
tance
Cable sheath
Electrical data
Operating voltage
Current consumption
• Transport and / or store the magnetic sensor in the unopened origi-
nal packaging.
• Protect the magnetic sensor from harmful physical influences includ-
ing dust, heat and humidity.
• Do not damage connections through mechanical or thermal impact.
• Prior to installation inspect the magnetic sensor for transport dam-
ages. Do not install damaged magnetic sensors.
Maintenance
With correct installation according to chapter
requires no maintenance. Clean the surface of the magnetic tape with soft
cloth from time to time if it is very dirty.
Disposal
The magnetic sensor's electronic components contain materials that are
harmful for the environment and are carriers of recyclable materials at the
same time. Therefore, the magnetic sensor must be recycled after it has
been taken out of operation ultimately. Observe the environment protec-
tion guidelines of your country.
8 Technical data
aluminum red
steel
aluminum green
aluminum uncoated, barrel-
finished
0.1 ... 2 mm
PUR, PVC
supply via measurement dis-
play / downstream electronic
unit
supply via measurement dis-
play / downstream electronic
unit
MS500 · Date 27.04.2018 · Art. No. 80296 · Mod. status 118/18
4
the magnetic sensor
Additional information
L design
F design
B design
B-TR design
6-wire ø5.1 mm
-0.2
Additional information
English
