Jetter AG
ID
Interface
Dez/Hex
6 PWMO_HS3
High-Side-PWM-
Ausgang (bis zu
3 A, mit genauer
Strommessung)
7 DO_HS3
High-Side-
Digital-Ausgang
(bis zu 3 A)
8 reserviert
9 reserviert
10/a CPWMO_HS3
High-Side-
Ausgang
(bis zu 3 A, mit
Stromregelung)
Betriebsanleitung – JXM-IO-EX30
Parameter
PWM_FRQ
DITHER_FRQ
DITHER_AMP
MAX_CURRENT
OVERCURRENT_TIME
FILTER_DEEP
MIN_DEVIATION
MIN_CURRENT
OPENCIRCUIT_DETEC-
TION
SENSOR_SUPPLY
MAX_CURRENT
FILTER_DEEP
OVERCURRENT_TIME
MIN_DEVIATION
MIN_CURRENT
OPENCIRCUIT_DETEC-
TION
SENSOR_SUPPLY
PWM_FRQ
DITHER_FRQ
DITHER_AMP
CURRENT_CONTROL_P
CURRENT_CONTROL_I
CURRENT_CONTROL_D
CURRENT_CON-
TROL_TIME
MAX_CURRENT
OVERCURRENT_TIME
FILTER_DEEP
MIN_DEVIATION
MIN_CURRENT
OPENCIRCUIT_DETEC-
TION
SENSOR_SUPPLY
Werte Status
O_DUTY_CYCLE OVERCURRENT
I_HCURRENT SUPPLY_FAULT
ERROR
INACTIVE
OPEN_CIRCUIT
O_DIGITAL OVERCURRENT
I_HCURRENT SUPPLY_FAULT
ERROR
INACTIVE
OPEN_CIRCUIT
I_HCURRENT OVERCURRENT
O_HCURRENT SUPPLY_FAULT
ERROR
INACTIVE
CC_UNLOCK
OPEN_CIRCUIT
Parametrierung | 8
