Assembly

Changing the Tool

Before any work on the machine itself, pull
the mains plug.
Selecting the Application Tool/Accessory
Accessory
BIM segment saw
blade
HCS plunge cut saw
blade, wood
Base plate for sand-
ing, series Delta
93 mm
HCS plunge cut saw
blades, wood*
BIM plunge cut saw
blades, metal*
HM-Riff segment saw
blade*
* Optional accessory; for the complete accessories please see Bosch accessory programme.
14 | English
When mounting the saw blade, wear protec-
tive gloves. Danger of injury when touching the
saw blade.
Material Application
Wooden materials, Separating and plunge cuts; also for sawing
plastic, non-ferrous close to edges, in corners and hard to reach
metals areas;
Example: shortening already installed bottom
rails or door hinges, plunge cuts for adjusting
floor panels
Wooden materials, Separating and deep plunge cuts; also for
plastic, gypsum and sawing close to edges, in corners and hard to
other soft materials reach areas;
Example: Sawing off water pipes (PVC) or
cable ducts flush against walls, floors or ceil-
ings
Depends on sanding Sanding surfaces close to edges, in corners or
sheet hard to reach areas;
Depending on the sanding sheet for, e.g.,
sanding wood, paint, varnish, stone, glass
Wooden materials, Smaller separating and plunge cuts;
plastic, gypsum and Example: Cut-outs in furniture for cable con-
other soft materials nections
Metal (e.g., nails, Smaller separating and plunge cuts;
screws, small profiles), Example: Shortening narrow profiles, cutting
non-ferrous metals fastening elements such as staples
Grouting joints, soft wall Cutting and separating close to edges, in cor-
tiles, glass-fibre rein- ners or hard to reach areas;
forces plastic and other Example: Removing grouting joints between
abrasive materials wall tiles for repair work, cutting openings in
tiles, gypsum boards or plastic
