B. If the laser beam is parallel with the marks,
but not going through them:
• Slacken the two screws. (Fig. 41b)
• The laser mounting block can now be moved
sideways to align the laser beam with the
marks made in the cardboard.
• When the laser beam is in the correct place,
re-tighten the two screws.
• Repeat procedure 'A' to check alignment.
Note: The above adjustments & alignments
should be checked on a regular basis to ensure
laser accuracy.
Note: The following WARNING labels can be
found on this machine:
LASER RADIATION
DO NOT STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
LASER RADIATION
AVOID DIRECT EYE CONTACT
PERMANENTLY MOUNTING
THE MITRE SAW
To reduce the risk of injury from unexpected
saw movement, place the saw in the desired
location either on a workbench or other
suitable machine stand. The base of the saw
has four mounting holes through which
suitable bolts (not supplied) can be placed to
secure the mitre saw. If the saw is to be used
in one location, permanently fasten it to the
workbench using appropriate fastenings (not
supplied). Use locking washers and nuts on the
underside of the workbench. (Fig. 43)
• To avoid injury from flying debris, position the
saw so that other people or bystanders cannot
stand too close (or behind) it.
• Locate the saw on a firm, level surface where
there is plenty of room for handling and
properly supporting the work-piece.
• Support the saw so the machine table is level
and the saw does not rock.
• Bolt or clamp the saw securely to its support
stand or workbench.
Note: This machine can be attached to the
Evolution Mitre Saw Stand. (Fig. 44). This will
provide a safe secure, and extremely portable
workshop stand which is capable of handling
long pieces of material. Operator efficiency
and safety may thus be enhanced, as well as
operator fatigue reduced.

FOR PORTABLE USE:

• Mount the saw on a 18mm thick piece of
plywood or MDF (800mm x 500mm min size
recommended) using appropriate fastenings
(not supplied).
Note: It may be necessary to countersink
the washers, nuts, etc. to the underside of
the plywood or MDF mounting board. The
underside needs to be smooth and flush with
no protruding fixings etc.
• Use 'G' clamps to attach the mounting board
to the work surface. (Fig. 45)
THE HOLD DOWN CLAMP
Note: One (1) Hold Down Clamp is provided
with the machine.
Two sockets (one either side) are incorporated
into the rear of the machines Fence.
These sockets are for positioning the Hold
Down Clamp.
To use the Hold Down Clamp during operations:
• Fit the clamp to the retaining socket that best
suits the cutting application, ensuring that it is
fully pushed down.
• Tighten the fence thumbscrew to lock the
pillar of the clamp into the fence socket.
• Place the work-piece to be cut onto the
saw table, against the Fence and in the
desired position.
• Adjust the clamp using the thumbscrews and
hand-wheel so that it securely holds the work-
piece to the saw table.
Conduct a 'dry run' with the power
disconnected. Ensure that the Hold Down
Clamp does not interfere with the path of the
blade, or with the path of any other part of the
cutting head as it is lowered to make the cut.
Note: The R210SMS includes the 2 piece clamp.
The R210SMS+ includes 3 piece clamp.
Front Clamp (Included with R210SMS+)
To fit the front clamp, place the rear of the
clamp into the holes at the front of the saw's
base. There are holes for the clamp located on
both left and right of the base. (Fig. 31)
OPERATING INSTRUCTIONS
Caution: All mitre saws should be inspected
(particularly for the correct functioning of the
safety guards) before each use. Do not connect
the saw to the power supply until a safety
inspection has been carried out.
