Wägecontroller CSD-918
Elementname Befehlsname
SAFETY CHECK1
SAFETY CHECK2
SAFETY CHECK3
SAFETY CHECK4
SAFETY CHECK5
SAFETY CHECK6
SAFETY CHECK7
SAFETY CHECK8
AUTOMATIC ACCUM.
CONDITION OF AUTO
ACM.
AUTO RECIPE CODE ACM. 73
AUTOMATIC PRINT
Ablaufsteue- Signalfunktion von Zu-
rungseinstel- lussstart
lung
START ABOVE ZERO
BAND
AUTOMATIC TARE
Düsenfunktion
NOZZLE CONTROL
CONTACT STOP SEQUEN-
CE
UP AFTER COMPENSATI-
ON
JUDGE CONDITION
Aktion bei Zulussende
MIXING START
DISCHARGE START
Aktionen bei Entleerungsende
TARE CLEAR
MIXING START
Aktionen bei Rezeptur-
start
RECIPE START ACTIONS
Aktionen bei Rezepturen-
de
DE-242
Befehl Nr.
73 51
73 52
73 53
73 54
73 55
73 56
73 57
73 58
73 61
73 62
63
73 64
74 01
74 02
74 03
74 04
74 05
74 06
74 07
74 08
74 09
74 10
74 11
Einstellwert der Befehlsrückgabe
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [ON], 2: [OFF]
1: [OFF], 2: [SYNC. WITH FINISH], 3:
[AUTO ACCUM. AT STABLE]
1: [IN OK MODE], 2: [NO CONDITION]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [TIMER IS UP], 2: [STAB. AND TIMER
IS UP], 3: [STAB. OR TIMER IS UP]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
1: [VALID], 2: [INHIBIT]
