Loudspeaker system
Tweeter
Midwoofer
Crossover
Frequency Response
Sensitivity
Nominal Impedance
Suggested amplifier
power output
Long-Term Max Input
Voltage (IEC 268-5)
Dimensions (HxWxD)
Net Weight (each)
2 way, full para-aperiodic passive radiator, wall mount loudspeaker system.
H28 XTR3. Silk dome 28 mm moving coil driver with DADTM, with vibration optimized me-
chanical interface. The ultra dynamic linearity is given by the Neodymium "cup design" motor
system.
MW15 XTR2-04 150mm cone driver. CCAW wire is used on a composite former "eddy current
free" voice coil. Special custom diaphragm made with a real time air dried non pressed blend
of traditional cellulose pulp and other natural fibers, developed according to the most natural
sound. Ultra-dynamic performance and high linearity. Sonus faber design.
Anti-resonant design, optimized amplitude/phase response for optimal space/time performan-
ce. "Paracross topology". Impedance compensation at low frequencies for a clear and friendly
amplifier performance. Highest quality is used in terms of the components: Jantzen inductors
and a new generation of Sonus faber capacitor designed in partnership with Clarity Cap.
Crossover Frequency: 2,500Hz.
50 – 35,000 Hz
87 dB SPL (2.83V/1 m)
4 ohm
35W – 250W
without clipping
20V rms
562 x 309,3 x 234,5 mm
22.1 x 12.1 x 10.9 in
9 kg
19.8 lb
Olympica Nova Wall
