MA502-S
32 Input mode
NOTICE
NOTICE

7.2 Incremental measurement

Precondition: Menu point 'Incremental measurement enable' (ABS/REL:)
(not for angle measurement 0°-90°-0°) in programming mode must be
programmed to "on", but unit must not be left in programming mode (see
5
chapter 'To leave programming mode').
Switching on by pressing the
• The display is zeroed.
• An "R" is displayed on position 1.
• Switching off by pressing the
ring value is displayed again.
• While in the incremental measurement mode the display can also be
set to zero by pressing key
surement in the background.

7.3 Reference and/or offset value modification

(offset value modification only SHOW: "lin")
Precondition: In programming mode menu points 'Reference value input
enable' (REF.EN:) 'Offset input enable' (OFF.EN:) respectively must be pro-
grammed to "on", but unit must not be left in programming mode (see
5
chapter 'To leave programming mode').
Change of reference value is enabled by pressing the
quent pressing of the
The display then shows the reference value, which can be changed via
the two arrow keys. By pressing the
taken over in the display.
Change of offset value is enabled by pressing the
pressing of the key (within 1 sec.) (only SHOW: "lin").
The display then shows the offset value, which can be changed via the two
arrow keys. Press key
If no key has been pressed for approx. 30 s or if you press again key
MA502 will return to display mode.
MA502-S · Date 13.03.2014 · Art. No. 81781 · Mod. status 422/13
key.
key once more. The absolute measu-
. This does not change the absolute mea-
key (within 1 sec.).
key, the value is saved and directly
to store the new value.
English
key, with subse-
key, with subsequent
,
