Internal Programs, Sound Control

Press the MODE button to select the internal program mode. When the display shows P, you can select the
desired internal program, with or without sound control, via the UP or DOWN buttons (see following graphic).
Mode:
P

Sound Control/Sensitivity

Press the MODE button until the display shows S. You can select the desired sensitivity via the UP or
DOWN buttons.
Mode:
S
S00 - S99 (S50 default setting)

DMX MODE

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED ML-56 QCL RGBW/RGBA 18x8W will respond to the controller.
Addressing
Press the MODE button until the display shows Add. You can now set the desired address via the UP or
DOWN buttons.
Setting the DMX Start Address:
Mode:
Add 001 - 512
Controlling:
After having addressed the LED ML-56 QCL RGBW/RGBA 18x8W, you may now start operating it via your
lighting controller.
Note:
It's necessary to insert the XLR termination plug with 120
proper transmission on the DMX data link.
Choosing a DMX Channel Mode with 3, 5, 7 or 8 channel occupation
The device has 4 DMX-modes. The Control Board allows you to assign the DMX-Mode.
Setting DMX Mode
After setting the desired address via the UP or DOWN buttons, press the MODE button again and the
display shows 7ch. Press the UP or DOWN buttons in order to choose the desired DMX Mode.
Mode:
7ch (default setting)
Value:
P01
Endless loop in 30 colors,
P02
P03
Endless loop in 30 colors,
P04
P05
Endless loop in 30 colors,
P06
Value
Value:
Value:
3ch
5ch
8ch
Function:
Endless loop in 5 colors,
change every 1 seconds
change every 1 seconds
Endless loop in 5 colors,
fade every 3 seconds
fade every 3 seconds
Endless loop in 5 colors,
via sound control
via sound control
in the last lighting in the link in order to ensure
