Specifications

Clear aperture (mm)
Parallax adjustment – range (side focus)
Eye relief (mm)
Eyepiece – diopter (min)
Eyepiece + diopter (min)
Field of view low power / ft@100 yds
Field of view high power / ft@100 yds
Reticle Adjustment at 100 yards per Click
Windage travel – total
Elevation travel – total
Main tube diameter
Overall length (inch)
Front mounting distance (inch)
Rear mounting distance (inch)
Weight (oz)
20
ZA 5 HD 1.2-6x24 ZA 5 HD 2-10x40
ZA 5i HD 1.2-6x24
24 40
100 yds. 100 yds.
101 101
2 2
2 2
81.2 48.7
16.2 9.7
0.5" 0.25"
≥ 90 MOA* ≥ 80 MOA*
≥ 90 MOA* ≥ 80 MOA*
30 mm 25.4 mm / 1.0"
10.23 12.74
3.41 2.20
2.27 1.96
12.5 16.0
ZA 5 HD 2-10x50 ZA 5 HD 3-15x42 SF
ZA 5i HD 2-10x50
50 42
100 yds. 50 yds. - ∞
101 101
2 2
2 2
48.7 32.5
9.7 6.5
0.25" 0.25"
≥ 80 MOA* ≥ 60 MOA*
≥ 80 MOA* ≥ 60 MOA*
30 mm 25.4 mm / 1.0"
12.37 12.98
1.90 2.30
2.27 1.96
18.0 17.6
