Forward
If you move the right-hand stick forward (away from you), the helicopter flies
forward.
Back
If you move the right-hand stick back (towards you), the helicopter flies
backwards.
Special notes
1.
If you find that the model's nose constantly turns in one direction, turn the
trim knob in the opposite direction until the rotation ceases.
2.
Circuit protection: when the transmitter cells are almost exhausted, the red
LED starts flashing. The transmitter automatically shuts down when the
LED has flashed nine times.
3.
The helicopter can be operated on three different channels (A, B or C).
Select the channel, switch the transmitter on, switch the helicopter on, and
you can start flying.
--
Throttle Forward
On / Off Back
Channel select switch
Charge monitor
--
Flying the model
1.
Switch the transmitter on: the red LED lights up.
2.
Keep the red dome of the transmitter pointing at the helicopter at all times.
3.
Place the model on a flat floor, and operate the On / Off switch on the
helicopter: the LEDs on the model light up.
4.
Check once more that there are no people, animals or other obstacles in
the vicinity.
5.
Move the throttle stick forward: the helicopter climbs.
6.
If necessary, turn the trim knob to trim the helicopter, then use the sticks to
control the model.
--
Off
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Änderungen vorbehalten! Keine Haftung für Druckfehler!
Left
Right
Trim left / right
20
09/2009
