Troubleshooting

Most diffi culties in audio systems are the result of poor or wrong
connections, or improper control settings. If you encounter problems,
isolate the area of the diffi culty, check the control settings, determine
the cause of the fault and make the necessary changes. If you are
unable to get sound from the RB-1510, refer to the suggestions for the
following conditions:

Front Panel Power Indicator Is Not Lit

No main power to the RB-1510. Check the front panel power
switch. Make sure that it is set to the On position. Check AC power
connections at the amplifi er and the AC outlet.

No Sound

If the amp is getting AC power, but is producing no sound, check the
Protection indicator on the front panel. If it is lit, see below. Also check
the front panel Level Controls to see if they are turned up. Then check
all of your connections and control settings on associated components.

Protection Indicator Is Lit

The front panel indicator lights when the RB-1510 protection circuits
have shut off the amplifi er. Typically, this occurs only when the
ventilation openings are blocked, when there is faulty speaker wiring,
or after a period of extreme use. Turn off the system and wait for the
amp to cool. Then push the front panel power switch in and out to
reset the protection devices. If the problem is not corrected or reoccurs,
there is a problem with the system or the amplifi er itself.
Specifi cations
Continuous Power Output Continuous Power Output
(20-20 kHz, < 0.03%, 8 ohms)
Total Harmonic Distortion (20Hz-20kHz, 8 ohms) Total Harmonic Distortion
Intermodulation Distortion (60 Hz : 7 kHz, 4:1) Intermodulation Distortion
Frequency Response Frequency Response ( ±1dB)
Damping Factor (20-20,000 Hz, 8 ohms) Damping Factor
Speaker Impedance Speaker Impedance
Signal to Noise Ratio (IHF A network) Signal to Noise Ratio
Input Impedance/Sensitivity Input Impedance/Sensitivity
Gain Gain
Power Requirements Power Requirements
U.S. version
European version
Power Consumption Power Consumption
Dimensions
Width x Height x Depth
Front Panel Height
Weight (net) Weight
All specifications are accurate at the time of printing.
Rotel reserves the right to make improvements without notice.
RB-1510 Stereo Power Amplifi er
65 watts/channel
< 0.03%
< 0.03%
15Hz - 50kHz
200
4 ohms minimum
108 dB
33 k Ohms/1.0 volt
27 dB
120 Volts, 60 Hz
230 Volts, 50 Hz
120 Watts
431 x 55 x 336 mm
3
17 x 2 / x 13
16
1U
4.3 kg, 9.5 lb.
1
/ ins.
4
