Temperature Relays and MINIKA®
Quick guide PTC-Thermistor-Relay MSR220K
1 Application and short description
ZIEHL PTC-resistor relays are designed for PTC-sensors according to DIN 44081 and DIN 44082. Therefor sensor and relays are
exchangeable. PTC-resistor sensors are suitable for the installation into windings of electrical machines, bearings and transformers as well
as to monitor the temperature of liquid media, airflow and gases.
Used in conjunction, they provide a effectively and reliable protection in case of
• blocking rotors, heavy starts, counter current operation
• undervoltage and phase failure
• increased ambient temperature and hindered cooling
2 Technical data
Rated supply voltage Us
Tolerance (voltage)
Tolerance (frequency)
Power consumption
PTC-resistor connection:
Number
Cut-out-point
Reclosing point
Reset input (Y1, Y2)
Current
Voltage
Relay output:
Contacts
Switching voltage
Switch-on current (NO)
min. voltage / current
Contact termination:
Protection class terminals
Actuation type
Number of levels
Solid conductor:
Fine-stranded conductor
Fine-stranded with insulated ferrule
with uninsulated ferrule
Housing:
Dimensions (w x h x d)
Protection class
Weigh
MSR220K 13000-0750-00
Mains Monitoring Digital Panelmeters MINIPAN®
AC/DC 24-240 V
AC/ DC 20,4...297 V
0/40...70 Hz
< 1,5 W / < 4 VA
PTC-sensor according to DIN 44081/82
set with 1 ... 6 PTC´s in series
3,3 kΩ...3,65 kΩ...3,85 kΩ
1,7 kΩ...1,8 kΩ ...1,95 kΩ
Potential free contact (no)
1 mA
< 30 VDC
EN 60947-5/IEC 947-5
2x 1 change-over contact (co)
max. AC 300 V; DC 300 V
AC 15 A 4s 10% ED
12 V 10 mA
Push-In spring-type terminal
IP20
Push-Button
1
1 x 0,14 mm
1 x 0,14 mm
1 x 0,25 mm
1 x 0,25 mm
Type K
22,5 x 75 x 115 mm
IP 40
IK06 1 J impact energy
ca. 140 g
Switching Relays and Controls
You can get further information and help via the
search for MSR220K
Datasheets, Operating Manuals and quick guides, Connection
Plans, CAD-Data, copious FAQ, Certificates.
0/50/60 Hz
... 1,5 mm / AWG 28 ... 16
2 2
... 1,5 mm / AWG 26 ... 14
2 2
... 0,75 mm
2 2
... 1,5 mm
2 2
page 3 / 4
ZIEHL industrie – elektronik GmbH + Co KG
Daimlerstr.13, 74523 Schwäbisch Hall, Germany
+ 49 791 504-0, info@ziehl.de,
Measuring Transducers Grid- and Plant Protection
updated: 2024-06-26 / dr
at ziehl.de.
3 Connection Plan
PTC PTC thermistor
Us Supply voltage
S1 Off switch
S2 Pusch button on
S3 Remote Reset
H1 Indicator lamp fault
F1-F4 Fuses
K1 Contactor
*1 external interlock
*2 MS-function
3.1 [*2] automatic reset
With bridged terminals Y1, Y2, the reclosing lock
function is disabled and a device type MSR works like a
device type MS.
MS types switch on automatically when the temperature
has decreased approx.
4 Connecting diagram
A1/A2
3650 ¦
1500 ¦
T1/T2
24 14
21 11
22 12
O N/A larm
GN RD GN
Y1 Y2
(Reset)
