1.4 Technical data
Operating pressure:
Nozzle size:
Flow cup:
Recommended viscosity*: 18-23 t (DIN/sec**)
*Viscosity is the flow rate of a spray material.
This viscosity is measured with a measuring/flow
cup***(not included in the scope of delivery). Meas-
ure the time in seconds until the liquid thread breaks
when running out. This run-down time is the viscosity.
Dilute the material until the liquid thread reaches the
time of 18-23 t (DIN/sec). **DIN/sec is an obso-
lete unit of measurement for viscosity, but is used by
do-it-yourselfers.
*** The measuring cup should have a capacity of
100 cm³. The outlet hole is 4 mm in size. Measurement
should ideally carried out at an ambient temperature
of 20°C.
Noise emission value
Measured value for noise emission value deter-
mined according to EN 14462. The weighted noise
level at the point of use is:
Sound pressure level: L
Uncertainty: K = 3.0 dB(A)
max. 3.5 bar
Ø 1.4 mm
approx. 500 ml
= 74 dB(A)
pA
