Automatic mode
In automatic mode, 4 show programs are available that run at an adjustable speed.
1
Press the MENU button so many times until Auto is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (Au01~Au04). Confirm with
the ENTER button.
2
Press the MENU button so many times until SPEE is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from SP 1 (slow) to
SP 9 (fast). Confirm with the ENTER button.
Sound control
Via the integrated microphone the unit can perfectly reproduce the show programs to the rhythm of the
music (sufficient bass provided).
1
Press the MENU button so many times until Soun is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (So01~So04). Confirm with
the ENTER button.
2
Press the MENU button so many times until SPEE is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from SP 01 (slow) to
SP 09 (fast). Confirm with the ENTER button.
3
Press the MENU button so many times until SEnS is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the microphone sensitivity to the volume of the music
(SE 01 = low, SE 09 = high).
4
If you enable the silent scene mode (on setting) in menu item SILE, the LEDs will switch off if the volume
is too low or if there is no sufficient bass beat. If you disable this mode (off setting) the LEDs remain on
during periods without music.
Individual color mix
In the color mode Colo each of the 4in1 LED spots can be individually adjusted for intensity. The device will
constantly emit the set color.
1
Press the MENU so many times until Colo is indicated in the display. Confirm with the ENTER button.
2
Now the display indicates the letter r for the color red and the corresponding intensity value. Use the
buttons UP and DOWN to adjust the desired value.
3
Confirm with the ENTER button. Now the color green can be adjusted, then blue and white.
Total brightness
Menu point diMM allows the adjustment of the total brightness for all stand-alone operating modes:
Press the MENU button so many times until diMM is indicated in the display. Confirm with the ENTER
button.
1
Use the buttons UP and DOWN to adjust the desired brightness (dI 01 = dark, dI 09 = bright). Confirm
with the ENTER button.
Bar Strobe LEDs
In Stro mode, you can set the strobe function of the white strobe LEDs.
1. Press the MENU button so many times until Stro is indicated in the display. Confirm with the ENTER
button.
2. Use the buttons UP and DOWN to choose on (strobe function on) or oFF (strobe function off). Confirm
with the ENTER button.
Behavior at missing DMX-signal
In DMX lost mode the program offers different options when no DMX signal is received.
1
Press the MENU button repeatedly until the display shows the DMX lost menu. Press ENTER to
confirm.
2
Select the desired program with the UP and DOWN buttons (see menu structure). Confirm with ENTER.
30/40
00132433, Version 1.1
