Universal Actuator
Disabling is deactivated.
The LED A1... (4) of the selected output or output pair flashes slowly.
Switching between Venetian blind and switching operation
Device is not in operation
￭
Activate permanent manual operation.
Press button Ǖ (1) repeatedly until LED A1... (8) of the desired output or
￭
output pair flashes.
Press the Ǖ (1) and Ǘ (4) and ǖ (5) buttons simultaneously for
￭
approx. 5 s.
Switching operation: Both status LEDs A1... (8) of the output pair light up.
Venetian blind operation: Both status LEDs A1... (8) of the output pair flash al-
ternately.
Press the Ǘ (4) and ǖ (5) buttons simultaneously.
￭
Outputs switch between switching operation and Venetian blind operation.
Both status LEDs A1... (8) indicate the current operating mode.
Press the Ǖ (1) and Ǘ (4) and ǖ (5) buttons simultaneously for
￭
approx. 5 s.
Operating mode switchover is terminated, permanent manual operation mode
is activated.
Press the Ǖ button (1) for approx. 5 s.
￭
Operating mode switchover is terminated, permanent manual operation mode
is deactivated.
5
Information for electrically skilled persons
DANGER!
Mortal danger of electric shock.
Disconnect the device. Cover up live parts.
5.1
Mounting and electrical connection
Mount device
In secure operation (preconditions):
–
Secure commissioning is activated in the ETS.
–
Device certificate entered/scanned or added to the ETS project. A high resolu-
tion camera should be used to scan the QR code.
82402638
9 / 14
21.11.2023
