During the storage of the device, the following rec-
ommendations must be observed:

protect the probes with a protective case,

make sure that the meter and accessories are dry,

when the devices must be stored for prolonged
period of time, batteries must be removed from
the device.
7

Dismantling and disposal

Worn-out electric and electronic equipment should be
gathered selectively, i.e. it must not be placed with
waste of another kind.
Worn-out electronic equipment should be sent to a
collection point in accordance with the law of waste
electrical and electronic equipment.
Before the equipment is sent to a collection point, do
not dismantle any elements.
Observe the local regulations concerning disposal of
packages and used batteries.
8
"d.v." used in the specification of measurement accu-
racy means "displayed value"
The device does not have the character of a standard
and therefore is not subject to calibration. The proper
form of control for this type of instrument is checking.
Voltage indication
Range
12...1000 V
AC/DC
DC voltage measurement
Range
-49,9...-6.0 V
6.0...49,9 V
-1000...-50 V
50...1000 V

In addition, the voltage values are indicated on
the LED scale as follows: 12, 24, 50, 120, 230,
400, ≥690 V, together with voltage polarization
("+" or "-" LED).
Input resistance
12 V, 24 V, 50 V
36
6

Technical specifications

Resolution
± 12 V, 24 V,
50 V, 120 V,
230 V, 400 V,
≥690 V
Resolution
U
we
120 V
230 V
400 V
690 V
P-4 ● P-5 ● P-6 – USER MANUAL

Storage

0.1 V
1 V
Accuracy
Complies with
EN 61243-2:2014
Accuracy
±(3% d. v. + 5 digits)
R
we
approx. 300 kΩ
