GP 135
("ON" button combination).
The cold start programme starts automatically
once the furnace has powered on.
Caution: No settings can be added during the igni-
tion phase.
Information:
A certain amount of odour may be created when
the vessel heats up for the first time. This does not
indicate a defect. This stops after a short while. Please
ensure the installation space is ventilated sufficiently.
The paintwork does not contain any toxic fumes.
Timer/weekly programme
Press the 1 button to get to the main menu.
Search for the pellet weekly programme by pressing
the 4 button and confirm by pressing 1 when you
have found this.
Buttons 4+5: you can use these buttons to change
the values that have been set.
Buttons 6+7: you can use these buttons to switch
between the menu points that have been described.
The selected menu point "flashes".
1 2
F01 WK 06:02 22°
P2 On Activated
6
7
1) Programme number
You can view the different power on/off times by
pressing the 1 button. You only have the option of
viewing programmes F01-F15. You are at F15 and you
can get back by pressing the 1 button. Start again as
described above.
4
3
5
8
2) Day of the week
Option to set each day individually (Sun, Mon, Tues,
Weds, Thurs, Fri, Sat) or the working days (WD) or
Saturdays and Sundays (WK).
3+4) hours and minutes
You can select the desired power on and off times
here.
5) Temperature
You can set the desired temperature here.
6) Heat output
You can select the heat output with which the
furnace turns on here. Later in its operation, the
furnace regulates the heat output itself, i.e. once it is
up to temperature, it regulates the heat output itself
automatically to the lowest level (P1) and, when the
temperature goes down, it switches back on and
turns the heat output back up again.
7) Mode
You can select whether this is the power on or off
time here. ON=EIN / OFF=AUS
8) Function:
You can use this menu point to select whether the
programme number is activated or No. A (deacti-
vated).
CAUTION!
During the times when programming is ON, the
furnace continues to run at the same temperature
and output as when it was last switched off.

Standby function

1. To get to the menu selection, press the 1 button
(set) to get to the
menu selection.
2. Select the menu point
"Change param. " using the 4 button.
3. Confirm this by pressing the 1 button (set)
4. Use button 6 to search for the menu point
"Standby function"
5. The standby function appears on the display.
6. Set the difference temperature using the 4 button
(min. 3 °C – max. 10 °C)
7. Confirm this with the 1 button (set)
8. The standby function is now active.
9. Leave the menu point by pressing the
3 button (on/off).
10. As soon as it has reached the set desired tem-
