Name
Settings
Behaviour on disabling
no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
No action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Behaviour on enabling
Continue control
ON
OFF
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
Slave input
inactive
ON
ON/OFF
This parameter defines whether the slave input expects an ON telegram or
whether it expects an ON and OFF telegram.
10.8 Photo-cell controller output
Name
Settings
Twilight threshold
2 lux .. 1000 lux
This parameter is used to select the light level from which to switch ON the
photo-cell controller output.
Disable output
No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
This parameter is used for selecting whether the output can be disabled,
and which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value
"0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value
"1".
Behaviour on disabling
no action
ON
OFF
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
No action: no further action takes place before disabling.
ON: output is switched ON before disabling.
OFF: output is switched OFF before disabling.
Behaviour on enabling
Continue control
ON
OFF
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
KNX Application Description for 3000-Series and IR Quattro Micro V3.1
10.9 Light level output
Factory setting
no action
Name
Send measured value
This parameter is used for selecting whether only to send the measurement
readings after any change or cyclically via bus.
Min. light-level change
This parameter is used to select which level the light level measured last sent
must have changed by before the light level measured is to be sent again.
Continue control
Send measured level
cyclically
Time interval for sending all measured light levels at cyclical intervals. The
cyclical sending mode can be set from 00:00:10 to 18:12:15.
10.10 Sabotage
Name
Interval for sending
cyclically
Time interval for cyclically sending the sabotage telegram as heartbeat. The
ON
cyclical sending mode can be set from 00:00:10 to 18:12:15.
Telegram
This parameter defines whether to send an ON telegram or OFF telegram
cyclically.
10.11 Logic gates 1...2 (all identical)
Factory setting
Name
50 lux
Logic gate type of logic
operation
This parameter defines the logic operation the gate performs.
No
Logic gate number of
inputs
This parameter defines how many inputs the gate has.
Logic gate type of output
object
This parameter selects output type.
Logic gate switching
command for logical 0
This parameter is used to configure which switching command is sent for a
logical "0".
Logic gate switching
command for logical 1
This parameter is used to configure which switching command is sent for a
logical "1".
Logic gate value
no action
for logical 0
This parameter is used to configure which value is sent for a logical "0".
Logic gate value
for logical 1
This parameter is used to configure which value is sent for a logical "1".
Logic gate
output sending behaviour
This parameter is used for setting output sending behaviour.
Continue control
Disable logic gate
This parameter is used for selecting whether the output can be disabled, and
which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value
"0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value
"1".
- 35 -
Settings
Factory setting
upon change
upon change
cyclically
1lux .. 255 lux
30 lux
hh:mm:ss
00:00:30
Settings
Factory setting
hh:mm:ss
00:01:00
ON
ON
OFF
Settings
Factory setting
OR; AND; exclusive OR
OR
1 ... 4
2
ON/OFF
ON/OFF
Value
ON; OFF
OFF
ON; OFF
ON
0 ... 255
0
0 ... 255
255
on changing logic;
on changing logic;
on changing logic to 1;
on changing logic to 0;
No
No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
